Variations in growth and genetic properties of Zea mays L. germinants exposed to cold shock



Abiotic stresses like low temperatures are contributory factors to the variations observed among species during plant germination, growth, and development. The present study evaluated the morphological and genetic responses of maize (Zea mays L.) seedling to cold shock induced by a one-time exposure to low temperature. Seeds were originally exposed to distilled water at room temperature for 48 h before they were completely submerged in buckets of ice for 0.5, 1.5, 3, 6, and 12 h, respectively, and then transferred into Petri dishes. The set up was left on the laboratory bench for an additional 5 days, and plant germination parameters were measured. DNA was extracted and this was followed by RAPD—polymerase chain reaction.


Significant growth impairment upon exposure to cold shock corresponding to the length of time of exposure was shown. The length of the prominent root significantly reduced upon exposure to a cold shock from 141.8 mm to as low as 91.4 mm in those plants exposed at 1.5 h. The length of the prominent leaf also significantly reduced from 100.6 mm in the control to between 62.6 and 85.5 mm in low-temperature-exposed plants (p < 0.05), notwithstanding the time of exposure. There were significant reductions in final germination percent in the low-temperature-exposed germinants (35.8–60.5%) when compared to the control (88.5%). The RAPD marker (OPA04) revealed variations in germinated maize seeds after treatment with different duration of low temperatures. The test plantlets treated for 0, 0.5, and 1.5 h have an unrecognizable complementary sequence to the primer OPA04, whereas the primer amplified regions of the genome of test plantlets treated for 3, 6, and 12 h. Primer OPA05 also presented diversity among maize seedlings stressed for various durations of cold shock.


The existence of genetic variations in the present study has far-reaching effects on the development of maize exposed to varying degrees of cold stress. Though restricted to germination only, they are important because the development of plants begins at the germination stage. These changes may affect the characteristics of economic importance or perhaps impact on the physiology of the maize plant eventually.


Plants form a critical piece of the diet of humanity. It is also believed that perhaps without plants the ecological food chain may not be entirely complete for the earth. However, environmental changes affect not only plant distribution, but also available even in areas where they were originally found to be naturally present (Ikhajiagbe and Omoregie 2020). This situation spells doom for food security across the globe. Agriculture and food security may be impacted by climate change globally. Most of the crops cultivated for food globally are grown in the tropics where productivity is significantly affected by atmospheric fluctuations. Most societies may not be able to mitigate the negative impacts of climate changes on the production of foods, maintenance of food quality, and adequate supply under socio-economic pressures (Ikhajiagbe and Omoregie 2020).

Currently, the agricultural sector in Nigeria is being transformed to meet food demands through an increase in the production capacity of most of these commodity crops (Iloh et al. 2014). Globally, maize (Zea mays L.) is ranked as one of the most useful cereals especially due to its valuable source of raw material for many industrial products (Dowsell et al. 1994). It is known to exceed all other cereal crops in Nigeria in terms of annual production and productivity (CSA, 2008). It is a staple food consumed by about 50% of the population of sub-Saharan Africa and is one of the priority crops to feed the ever-increasing population of the country (Iloh et al. 2014). In the developing world, the importance of maize cannot be overemphasized and this includes the potential to alleviate or mitigate the present food insecurity and poverty. Maize is a crop having a short life cycle, which requires warm weather and appropriate management. The forest ecology in Nigeria is where most of the maize is grown, but due to higher yield potential, it is produced in the northern Guinea savannah in large scale capacity. However, with the increasing threat of erratic weather conditions, the question would be what impact would a rather significantly low temperature have on maize development as well as genetic properties?

Ordinarily, low temperatures affect different aspects of the growth of crops; photosynthetic and mitotic abilities necessary for their survival and reproduction, water assimilation, and transport for their growth and yields. The cell changes that are prompted by temperature changes include reactions that lead to the accumulation of harmful compounds, particularly reactive oxygen (ROS) (Mittler, 2002). Improved photosynthetic electron transition to oxygen and a significant decrease of the respiratory electron transport chain can likewise result in oxidative stress from the accumulation of ROS during chilling (William et al. 2004). Plants have adopted a variety of responses to changes in temperature in order to limit damages and ensure that cell homeostatic processes are maintained (Kotak et al. 2007). Distinctive plant ponders have uncovered that improving antioxidant defense is a strategy that induces tolerance to stress caused by abnormal temperature changes (Huang and Guo 2005). Seed germination is profoundly subject to temperature because it is one of the fundamental essentials of the germination process. In any case, the scope of temperature wherein seeds perform better germination depends to a great extent on crop species (Yuan and Wen 2018).

Plant germination begins with the take-up of water by inactive dry seeds and ends with the lengthening of the embryonic axis (Bewley and Black 1994). Germination alludes to the process by which the organism develops either from seed or comparable structure. The most common cases of germination include the growth of a seedling from a seed of either an angiosperm or gymnosperm (Alvarado and Bradford 2002). Natural factors have been shown to affect seed germination (Rizzardi et al. 2009). The periodicity of seed germination has been shown to be significantly affected by temperature changes especially low temperature which generally influences plant development and the profitability of crops and prompts generous crop misfortunes (Xin and Browse, 2000; Wahid et al., 2007; Guan et al. 2009). Studies have shown that plants which originate from temperate regions are tolerant to chilling effects when compared to those of tropical and subtropical origins which do not have such an adaptative mechanism to a cold environment (Xin and Browse 2000; Sanghera et al. 2011).

The physiological processes of plants are to a great extent influenced by the change of environmental temperature. The capacity of plants to adapt to an extreme temperature is a process that is complex and dictated by ecological elements and by the hereditary ability of the plant (Balkaya 2004). Generally, exposure to cold temperature influences crop development and growth in two different ways concurrently. First, the development events in the shoot apex are influenced which legitimately decide the differentiation of the panicle and subsequently potential yield and spikelet fertility leading to fewer grains. Secondly, photosynthesis is impeded which hinders growth and results in indirect yield because there is less sugar accessible for grain production (Takeoka 1992). Gan et al. (2004) observed that cold stress prompted morphological side effects like a stunted plant, bushy plants, premature development, and yellowing of leaves. During chilling stress decrease in ribosomal numbers, dilation of the endoplasmic reticulum, and vesiculation of the cytoplasmic membrane was observed (Ishikawa 1996). The outcome of cold stress quickened senescence and plant death (Sharma et al. 2001). The investigation of the effects of non-lengthy exposure of maize germinants to low temperatures on its growth and genetic disposition, using RAPD has become necessary and also, due to the need of increasing maize production in the face of climate change, this study was to determine variations in phenotypic and genotypic responses of maize seedling exposed to cold shock for improved knowledge and resources in breeding programs.

Material and methods

The experiment was carried out in the pre-degree laboratory of the Department of Plant Biology and Biotechnology, University of Benin, Benin City. At the end of the experiment, seed drying was carried out at the Faculty of Agriculture Laboratory, University of Benin.

Initiation of germination and exposure to cold shock

Germination initiation was achieved by placing dry viable seeds in Petri dishes for 48 h on tissue paper that was originally moistened with distilled water. Ten seeds were placed on each Petri dish. The 10 seeds each that were placed into the Petri dishes were removed from the Petri dishes and immediately transferred to ice cube-filled transparent buckets (40 cm in height, 22 cm in diameter). Crushed ice was first placed in the buckets and made to the 10 cm mark of the transparent buckets before maize seeds were placed carefully, and then, ice cubes were placed over seeds till the transparent bucket was full of ice block.

Replacement and time intervals

The ice in the transparent buckets was continually being replaced with more ice cubes as soon as they melted, till the time frame specified for each treatment was achieved. Seeds were left in the ice buckets for 0.5, 1.5, 3, 6, and 12 h, respectively, before they were carefully removed and transferred into Petri dishes. It should be noted that the control was not exposed to ice.

Placement in Petri-dishes

Upon exposure of seeds to ice (cold) at different time intervals in the transparent buckets, they were later removed and placed back into the Petri dishes after completion of the time frame for exposure to cold. Petri dishes were replicated thrice.

Germination parameters and chlorophyll content (CCI)

Plant germination parameters measured were root length, plant height, length of prominent root, and length of the prominent leaf. Wet weights of roots, leaves, and those of seedlings were measured using the weighing balance after the day of termination of the experiment. Their respective dry weights were also measured after drying in an oven at 50 °C for 2 days. The foliar chlorophyll content index (CCI) was measured using a chlorophyll content meter according to methods described by Ikhajiagbe et al. (2017).

Germination test formula

Rate of germination index (RGI)

$$ \mathrm{RGI}=\frac{\mathrm{Number}\ \mathrm{of}\ \mathrm{seedlings}\ \mathrm{at}\ 7\ \mathrm{days}}{\mathrm{Number}\ \mathrm{of}\ \mathrm{seedlings}\ \mathrm{at}\ 14\ \mathrm{days}}\mathrm{x}100 $$
$$ \mathrm{GRI}\ \left(\%/\mathrm{day}\right)=\left({\mathrm{G}}_1/1\right)+\left({\mathrm{G}}_2/2\right)+\dots +\left({\mathrm{G}}_{\mathrm{n}}/n\right) $$

where G1 is germination percentage (%germ) at 1st day, G2 is %germ at 2 days, Gn is %germ at n days, divided by n (no. of days for which that germ. percent was calculated).

GRI shows the %germ on each day of the germination period.

Time spread of germination (TSG)

The TSG is the time taken between the first and last germination events which occur in a seed lot. It is measured in days and a greater difference in time difference is indicated by a higher TSG (Al-Mudaris 1998).

The germination index (GI)

The GI was calculated using the equation stated by the Association of Official Seeds Analysts (AOSA 1983) as shown below

$$ \mathrm{GI}=\frac{\mathrm{No}.\kern0.5em \mathrm{of}\ \mathrm{germinated}\ \mathrm{seed}}{\mathrm{Days}\ \mathrm{of}\ \mathrm{the}\ \mathrm{first}\ \mathrm{count}}+\frac{\mathrm{No}.\kern0.5em \mathrm{of}\ \mathrm{germinated}\ \mathrm{seed}}{\mathrm{Days}\ \mathrm{of}\ \mathrm{the}\ \mathrm{final}\ \mathrm{count}} $$

Higher GI indicates a higher germination percentage and rate.

Coefficient of the velocity of germination (CVG)

The CVG was determined by a mathematical equation stated by Scott et al. (1984). The equation is shown below

$$ \mathrm{CVG}=\frac{\Sigma \mathrm{Ni}}{\Sigma \mathrm{Ni}\mathrm{Ti}}\times 100 $$

Mean daily germination (MDG)

The MDG which is an index of daily germination was calculated from the equation below

$$ \mathrm{MDG}=\mathrm{FGP}/\mathrm{d} $$

Mean germination time (MGT)

The MGT which is an index of daily germination was calculated from the equation below

$$ \mathrm{MGT}=\frac{\sum \mathrm{f}\mathrm{x}}{\sum \mathrm{f}} $$

where f = seeds germinated on day x.

The lower the MGT, the faster a seed population has germinated.

First day of germination (FDG)

This was measured as the first day of germination.

Prominent foliar color

The prominent foliar color was determined using the color code downloaded from Google App Store.

Determination of total sugars

Water was added to a measured 0.1 ml/0.2 ml of sample extract to make up 1 ml. Then, 1 ml of phenol solution and 5 ml concentrated H2SO4 were added. The resultant solution was boiled for 20 min in a water bath and read via UV-VIS spectrophotometer (Spectronic 21 D, England) at a wavelength of 490 nm after it had cooled off. A standard calibration curve was determined first from a standard solution also ran at 490 nm (Fig. 1).

Fig. 1
figure 1

Calibration curve for the determination of Total Sugars

Random amplified polymorphic DNA (RAPD) polymerase chain reaction

The RAPD-PCR was carried out according to methods described by Ikhajiagbe and Omoregie (2020). “The RAPD-PCR was carried out on the extracted DNA sample using the RAPD primer OPA 04 (5′-AAT CGG GCT G-3′). The PCR reaction was carried out in a 20 μl reaction mixture containing 1X PCR buffer (Solis Biodyne), 2.5 mM magnesium chloride, 0.2 mM of each dNTP, 40 pMol of primer, 1 U Taq DNA polymerase, 10–200 ng of DNA, and sterile deionized water was used to make up the reaction mixture. Amplification was carried out in an Eppendorf Nexus thermal cycler using the following cycling parameters; an initial denaturation at 95 °C for 5 min which was followed by 40 consecutive cycles of 95 °C for 1 min, 30 °C for 1 min, and 72 °C for 2 min. This was followed by a final extension of 72 °C for 10 min. The PCR products were separated on a 1% Agarose gel and 1 Kb DNA ladder (Fermentas) was used as DNA molecular weight standard”.

Statistical analysis

The experimental design adopted for the present study was the complete randomized experimental design. Therefore, a single factor analysis of variances (ANOVA) was necessary. Results were thereafter presented in means of 5 replicates, and treatment means were separated by using Duncan multiple range test at a 95% confidence limit. Statistical analyses were performed using the SPSS® version 23 as well as the Microsoft Excel was used where necessary.


The plant height of maize germinants after exposure to cold shock has been presented in Fig. 2, where results for the control experiments showed progression in plant height from 30 mm on the first day to 55.5 mm on the 4th day after exposure to cold shock. However, when results were compared to germinants exposed to cold shock, it was observed that at the first day following plant exposure, plant heights ranged from 2 mm in those germinants exposed at 1.5 h to 10 mm in those germinants exposed at 6 h. However, on the 4th day after exposure of plants to cold shock, plant height reduced from 55.2 mm in the control to 25.4 mm in germinants exposed at 0.5 h and 17.8 mm in germinants exposed at 1.5 h.

Fig. 2
figure 2

Effects of cold shock on plant height of maize germinant (DACS days after exposure to cold shock)

The effects of cold shock on the root length of maize germinants have been presented in Fig. 3 below, 1 day after exposure to cold shock; root length was 3.6 mm for seedlings exposed at 0.5 h and 8 mm for those exposed at 12 h, compared to 9.2 mm in the control. However, 4 days after exposure to cold shock root length was highest in the control (74.2 mm) and significantly reduced in the seedlings exposed to cold shock with values ranging from (24.6–40.2 mm).

Fig. 3
figure 3

Effects of a cold shock on root length of maize germinant (DACS days after exposure to cold shock)

Table 1 and Plate 1 show the effects of cold shock on germination parameters of the maize plants at 7 days after germination was initiated (or the 5th day after plants were exposed to cold shock). The length of prominent root significantly reduced upon exposure to the cold shock from 141.8 mm to 91.4 mm in those germinants exposed for 1.5 h. The length of the prominent leaf also was insignificantly reduced from 100.6 mm in the control plant to between 62.6 and 85.5 mm when germinating seeds were exposed to cold shock irrespective of the time of exposure. However, exposure of plants to cold shock did not significantly change the number of roots per plant in the germinants (6–9 roots per plant, p > 0.05). Similarly, no significant changes in chlorophyll content index of the leaves of the germinated seeds were observed irrespective of exposure to cold shock; chlorophyll content index, therefore, ranged from 3.7 to 6.9 CCI. Results also showed that the exposure of maize plants to cold shock insignificantly changed both dry weight and wet weight of the germinated seeds as well as of the developing seedling (Table 1).

Table 1 Effects of cold shock germination parameters of maize at 7 days after germination initiation
Plate 1
figure 4

Experimental treatments at 7 days after germination initiation or 5 days after exposure to cold shock

The results as presented in Fig. 4 showed that at 24 h (or 1 day) after exposure, the germination percentage was 40% in the control, compared to 26.7–33.33% in the exposed seeds. Final germination percent was achieved generally 5 days after exposure except for those seeds that were exposed in cold shock for more than 3 h. Figure 5 shows the final germination percent (FGP) of maize seeds at 7 days after exposure to cold shock. Whereas FGP was 83.3% in the control, it significantly reduced as exposure time to cold shock persisted. FGP in the seeds exposed for 12 h was 40.0%, and this represented a 51.98% loss in germination when compared with the control. Generally, loss in germination also increased with persistence in exposure time to cold shock.

Fig. 4
figure 5

Progression in germination percentages of germinant exposed to cold shock at different time intervals

Fig. 5
figure 6

Final germination percentage at 7 days after exposure to cold shock (FGP final germination percent, LGP loss in germination percent)

Germination indices were calculated during the course of the study and presented in both Tables 2 and 3. The time taken for the first germination to occur in the control was 29.5 h (Table 2). However, this time was further delayed upon exposure of the plant to cold to as much as 30.1 h, although this delay was minimal (p > 0.05). However, the time taken to reach the last germination was significantly delayed when the plants were exposed to cold shock for more than 6 h prior to germination (116.2–134.8 h), as compared to 98 h in the control seedling. For such a plant also, it was observed that they did not attain 50% germination as compared to the control plant which attained 50% germination in 80.4 h. Table 2 also shows that the speed of germination was reduced upon exposure to cold shock; germination seed in the control was 68.9% per hour compared to 105.4% per hour in seeds exposed to cold shock for 12 h.

Table 2 Germination index I of the test plant upon exposure to cold shock
Table 3 Germination index II of the test plant upon exposure to cold shock

The results as presented in Table 3 show that there were no significant changes in mean germination time irrespective of exposure of the plant to cold shock (111.6–116.6 h, p > 0.05). Similarly coefficient of the velocity of germination expressed as the number of plants per day also did not significantly differ when control seeds were exposed to cold shock. Results varied from 0.206–0.215 per day. Germination rate as calculated in the present study however has significantly decreased from 1.6 seeds per day in the control compared to 0.5 seeds per day when exposed to 12 h of cold shock (p = 0.036). Similarly, mean daily germination also significantly increased from 12.9% per day in the control to 4.3% per day in seeds exposed for 12 h.

Total sugars in the plumule were 5.3 mg/ml at 24 h after seeds were exposed to cold shock (CS) for 5 h, compared to 6.2 mg/ml in the control. However, at 60 h after exposure, total sugar ranged from 13.2 to 17.3 mg/ml in the seeds exposed to cold shock, compared to 20.1 mg/ml in the control (Fig. 6a). In the radicle, however, sugars ranged from 12.0 to 18.8 mg/ml 24 h after exposure to 25.4 to 31.4 mg/ml at 60 h after exposure, not minding the level of seed explore (Fig. 6b). Residual sugars were higher in the control (20.3 mg/ml) than in the exposed germinants (10.3–17.2 mg/ml) at 60 h following the exploration (Fig. 6c).

Fig. 6
figure 7

Total residual sugars in maize a plumule, b radicle, and c germinated seed 60 h after exposure to cold shock regimes (h.aCS hours after exposure to cold shock)

The RAPD marker presented showed variation in germinated maize seeds after treatment with different duration of low temperature (Fig. 7). The test plantlets treated for 0 min, 30 min, and 1.5 h have an unrecognizable complementary sequence to the primer OPA04, whereas the regions of the genome of test plantlets treated for 3, 6, and 12 h were amplified by the primer. These plantlets were subjected to a long duration of stress by low temperature and may have provided some adaptive mechanism which the primer OPA04 recognized. Sample 4 (3 h of stress) had 4 bands of sizes 500, 600, 700, and 800 bp. Sample 5 (6 h) had the same 500 and 600 bp fragments but had another 550 bp product that was absent in sample 4. The plantlets subjected to the longest duration of cold stress in this study (sample 6) had smaller fragments of about 100, 180, and 400 bp alongside the other bands observed in samples 4 and 5 (Fig. 7).

Fig. 7
figure 8

RAPD-PCR gel photograph showing genetic variation using primer OPA04. Keys: L; 100 bp ladder, 1 no cold shock, 2 0.5 h cold shock, 3 1.5 h cold shock, 4 3 h cold shock, 5 6 h cold shock, and 6 12 h cold shock

Primer OPA05 presented diversity among maize seedlings stressed for various durations. The banding patterns observed in Fig. 8 are different for all treatments. The fragment of about 1200 bp was the only band common to the six treatments. Treatment 3 had only the 1200 bp band while the others had polymorphic bands. Test plants stressed for 30 min had a unique fragment of 200 bp. Those stressed for the longest duration of 12 h had a band of about 350 bp absent in the other treatments. There was also a 300 bp product observed in samples that went through 3 h of cold stress. In comparison with the control (sample 1), plants stressed for 30 min, 3 h, and 12 h had more similar amplified products than those stressed for 1.5 h and 6 h. OPA05 presented a high level of diversity among the various duration of cold stressed maize seedlings.

Fig. 8
figure 9

RAPD-PCR gel photograph showing genetic variation using primer OPA05. Keys: L; 100 bp ladder, 1 no cold shock, 2 0.5 h cold shock, 3 1.5 h cold shock, 4 3 h cold shock, 5 6 h cold shock, and 6 12 h cold shock

There was no amplification in both the stressed maize seedlings and the control when primer OPA08 was used. This primer had no recognizable sequence in the genome of maize extracted in this study (Fig. 9).

Fig. 9
figure 10

RAPD-PCR gel photograph without amplification using primer OPA08. Keys: L 100 bp ladder, 1 no cold shock, 2 0.5 h cold shock, 3 1.5 h cold shock, 4 3 h cold shock, 5 6 h cold shock, and 6 12 h cold shock


The result obtained from the experiment carried indicated that exposing maize germinants to cold shock had a significantly negative effect on germination. It was well noted that the control had a higher percentage of germination compared to the other maize germinates exposed to cold shock; therefore, implying that cold shock drastically reduces or slows down germination. During the course of the experiment, it was noticed that time taken to reach the last germination was significantly delayed when plants were exposed to cold shock for more than 6 h prior to germination. It was noticed also that no significant changes were made in mean germination time irrespective of exposure to cold shock (p = 0.613). The coefficient of the velocity of germination also had no significant changes (p = 0.427). Stress resulting from very low temperature (chilling stress) significantly affects germination, delays plant development, and reduces seedling vigor which culminate in yield loss. This stress induces deficiency in shoot water as a result of decreased uptake of water by the roots (Stewart et al. 1990; Kang and Saltvelt 2002; Wang et al. 2012).

Recent studies on maize revealed that chilling severely damaged the shoot and growth attributes, compared with control. Significant reductions in lengths of prominent leaves and roots respectively, as well as the heights of the plants, were reported. Chilling stress could also cause a necrotic lesion on leaves, delay leaf development, prolong cell cycle with decreased cell production, induce wilting, and increase susceptibility to pathogens and diseases (Korkmaz and Dufault 2001; Rymen et al. 2007). Cold shock (chilling stress) also has a negative effect on growth parameters, and the following observations were made: impaired root length and low chlorophyll index (CCI). Dry weight and wet weight were both significantly changed.

Tissue necrosis resulting from compromised membrane integrity and altered enzyme activities are negative impacts of chilling stress (Chinnusamy et al. 2007). This is related to changes in DNA, RNA, and protein structural make-up as a result of excessive ROS generation is a consequence of plant exposure to cold stress. This may be related to the ability of cold stress to induce osmotic imbalance as well as alter the plants’ metabolism at its cellular level. Thus, there is a decreased amount of produced ATP from low respiration (Sadeghi et al. 2011). To mitigate the harmful effect of oxidation caused by unfavorable conditions such as chilling, plants have developed specialized antioxidative mechanisms involving a system of enzymatic and non-enzymatic antioxidants (Gill and Tuteji 2010). It is suggested that perhaps those germinants where changes in growth parameters were compared with the control (0.5–1.5 h) may have grown chilling stress defense mechanism for coping with the latter; this was not determined in the study though.

The genetic diversity in Z. mays exposed to cold shock at different time intervals was evaluated using the RAPD molecular markers. The existence of genetic variations in the present study has far-reaching effects on the development of maize exposure to varying degrees of cold stress. These changes may affect the characteristics of economic importance or perhaps impact on the physiology of the maize plant eventually.


The study thus showed significant growth impairment as the time of exposure increased. The findings of the study, though restricted to germination, are critical because the development of plants begins at the germination stage. Most times, factors that impair germination eventually go on to impair the generality of the plant’s growth and development. Given the fact that results presented also showed differences in genetic characteristics (via RAPD assessments) upon exposure to cold shock, it has far-reaching implications for the plants’ genetic characteristics. Though the extent of genetic changes was not investigated in this study, further study is suggested to assess aspects of specific genetic characteristics that were modified by exposure to cold shock as well as a possible physiological basis for interpreting the results of the present study.
