Nitrilase gene detection and nitrile metabolism in two bacterial strains associated with waste streams in Lagos, Nigeria

Abstract

Background

The use of nitrile compounds is usually high, particularly in chemical industries, which calls for serious concern because of their relevance to the environment. The essential role of nitrilases in the bioremediation of harmful nitriles from environmental wastes cannot be overemphasized. The study aimed to unveil the biodegradative potentials of bacterial strains associated with the degradation of nitrile pollutants.

Methods

Bacterial strains capable of utilizing glutaronitrile as the sole source of carbon and nitrogen were isolated from solid waste leachates by a selective enrichment culture technique. The test organisms were grown in mineral salts medium (MSM), and the metabolic products were determined using gas chromatography-flame ionization detection (GC-FID). The nitrilase gene was amplified by polymerase chain reaction (PCR) and by using appropriate primers.

Results

The growth studies showed that the test organisms grew on the two nitriles. The doubling times of 12.16 d and 9.46 d (specific growth rate, µ=0.082 d⁻¹, 0.106 d⁻¹) were obtained for  each pure culture of Bacillus sp. srain WOD8 and Corynebacterium sp. srain WOIS2 on glutaronitrile (as single substrate), respectively. While the same strains  had doubling times of 11.11 d and 10.00 d (µ=0.090 d⁻¹, 0.100 d⁻¹) on benzonitrile (as single substrate). However, the mixed culture (comprising the two strains)  had doubling times of 7.40 d and 7.75 d (µ=0.135 d⁻¹, 0.129 d⁻¹) on glutaronitrile (as single  and mixed substrates), respectively.  While doubling times of 8.09 d and 8.71 d (µ=0.124 d⁻¹, 0.115 d⁻¹) were obtained  for the same mixed culture on  benzonitrile (as single and mixed substrates). Based on gas chromatographic analysis, the residual glutaronitrile concentrations at day 16 for strains WOD8 and WOIS2 were 35.77 g L⁻¹ (72.2%) and 9.30  g L⁻¹ (92.5%), respectively, whereas the residual benzonitrile concentrations for the same strains were 27.39 g L⁻¹ (78.8%) and 13.79 g L⁻¹ (89.2%), respectively. For the mixed culture, residual glutaronitrile and benzonitrile concentrations at day 16 were 13.40 g L⁻¹ (88.5%) and 10.42 g L⁻¹ (91.5%), respectively, whereas for the mixed substrates  (glutaronitrile and benzonitrile), 7.21 g L⁻¹ (91.7%) and 4.80 g L⁻¹ (94.2%) of residual glutaronitrile and benzonitrile concentrations were obtained by the same consortium. The gene for nitrilase involved in nitrile degradation was detected in the genome of the bacterial strains. The amplified nitrilase gene gave PCR products of sizes 1400 bp and 1000 bp, as expected for strains WOD8 and WOIS2, respectively. 4-Cyanobutyric acid (4CBA), glutaric acid (GA), and benzoic acid (BA) were obtained as metabolites following nitrile degradation in vitro.

Conclusion

These results revealed that strains WOD8, WOIS2 and the mixed culture (consisting of the two strains) have proven to have the capacity to metabolize nitriles (glutaronitrile and benzonitrile) as the carbon and nitrogen sources. However, the mixed culture had higher nitrile degradation rate as compared to each pure culture of the two test organisms. These results also provide insight into the evolutionary genetic origin of a nitrilase gene that encodes an enzyme that catalyzes nitrile degradation in these strains. Hence, the bacterial strains that harbor this kind of gene may be used as promising biological agents for the remediation of sites polluted with nitriles, thereby opening new perspectives for encouraging data for a bioremediation bioprocess.

Background

Bacterial nitrilases are responsible for the degradation of nitriles into corresponding carboxylic and ammonia. Some of the benefits, such as working under mild response conditions, being regioselective, and enantioselective, are reasons behind the wide usage of nitrilases over the usual chemical procedures (Wang et al. 2014; Vejvoda et al. 2010). Eventually, nitrilases are considered a reasonable candidate to drive the age of numerous useful carboxylic acids. Nitrilases, as important biocatalysts, convert a variety of nitriles to carboxylic acids, thereby facilitating more environmentally friendly chemical and pharmaceutical production (Ramteke et al. 2013). Nitrilases are found all over the world and are critical components of metabolic pathways as well as a response to environmental stimuli such as nitriles, whether natural or man-made. Nitrilases are frequently found in gene clusters on a genome that represent their metabolic roles (Podar et al. 2005). Nitrilase in bacteria and fungi has been studied (Kaplan et al. 2006; Vejvoda et al. 2006, 2008; Martínková et al. 2009; Gong et al. 2012; Egelkamp et al. 2017). Layh et al. (1998) reported that nitrilase producing bacteria use nitriles as a nitrogen source for growth as a result of nitrilase expression. In bacteria, however, nitrilases are uncommon, with only 10 nitrilase genes discovered in over 150 genomes analyzed (Podar et al. 2005). Sharma et al. (2017) discovered just 138 nitrilases in 2000 bacterial genomes after using genome mining data. According to these findings, nitrilases are expressed by just 6.8% of bacteria.

Recently, nitrilases have drawn general attention after the recognition of their enormous prospective uses in industry and bioremediation activities (Sharma et al. 2017). Usually, most nitriles are extremely toxic and have become an environmental issue that requires serious concern. Consequently, viable action towards reducing the nitrile-based wastes delivered from a few manufacturing processes is required. However, cyanogenic compounds have surfaced in some medical problems, including other primary central nervous system (PCNS) symptoms.

Moreover, cyanide anions formed from nitriles could be harmful by prompting the deactivation of respiration brought about by a strong affinity to cytochrome-c-oxidase (Kaul et al. 2007). With the inherently destructive and unfavorable effect of cyanide-based compounds, they can cause damage to living organisms and the environment (Kaul et al. 2007; Gupta et al. 2010; Banerjee et al. 2002). A few nitrile compounds are made and used as solvents, plastics, polymers, and herbicides (Kobayashi et al. 1990), while a few nitriles are used as raw constituents or biosynthetic precursors in generating pharmaceuticals, fine chemicals, and other useful products (Kaul et al. 2007). The exuberant increase in nitrile biotransformation (Mathew et al. 1988) and degradation of nitrile-derived herbicides (Stalker et al. 1988) have confirmed the investigation regarding bacterial strains as the basis of these events. Lagos is a metropolitan city in Nigeria where few dumpsites exist.

This places an unexpected population of 180 million individuals in danger of cyanide toxicity. The present study aimed to reveal the bioremediation potentials of bacterial strains associated with nitrile degradation in Nigeria in order to strongly decrease health-risk factors in the ecosystem.

Methods

Source of metabolizing bacterial strains

Metabolizing bacterial strains, Bacillus sp. WOD8 (KX774193) and Corynebacterium sp. WOIS2 (KX774194) used was previously described by Ogunyemi et al. (2019). Bacteria capable of metabolizing glutaronitrile as the sole carbon and nitrogen source were isolated from solid waste leachates by a selective enrichment culture technique (Ogunyemi et al. 2019). Previously, these strains have shown ample ability to use glutaronitrile and benzonitrile for growth (Ogunyemi et al. 2019). The bacterial strains were revived and ready for further studies.

Evaluation of growth potentials on nitriles

This experiment was conducted to examine the ability of the bacterial species as pure  and mixed culture to utilize nitriles. The laboratory tests were carried out in duplicate under aerobic conditions in Erlenmeyer flasks (250 ml). The constituents of MSM (g/L) included NaCl, 0.20; MgSO₄.7H₂O, 0.050; K₂HPO₄, 2.0; KNO₃, 2.0; CaCO₃, 0.020; and FeSO₄. 7H₂0, 0.010; 1000 mL distilled water, pH, 7.0 ± 0.2), fortified with 1.0 mL of sterile trace element solution (Santoshkumar et al. 2011). The medium was supplemented with 0.2% (v/v) nitrile as the sole carbon and energy source. The bacteria inoculum for the major biodegradation studies was prepared by growing each test organism in MSM and incubated at 48 h to allow the cells to fully grow to mid log phase. While the mixed culture inoculum , the cells harvested were in equal proportion with a corresponding cell density of 10⁸ cfu/ml for each. The Erlenmeyer flasks (250 mL) containing 100 mLof  MSM  was inoculated with 1.0 mLof inoculum (pure and mixed culture) and incubated (30 ºC, 150 rpm) for 16 days.   To monitor contamination and the effects of abiotic factors, two flasks of mineral salts medium  acted as negative and positive controls. Flasks were incubated for 16 days. The growth experiments were set up in triplicate. The culture (5.0 mL) from the sets of flasks was harvested every 4 days to determination of turbidity. The increase in turbidity of the culture broth was used to monitor the growth of both pure and mixed culture (Bacillus sp. strain WOD8 and Corynebacterium sp. strain WOIS2) at a wavelength of 600 nm using a spectrophotometer (Thermo-scientific™ Spectronic GENESYS 8, Thermofisher Scientific, USA). Generation times and the specific growth rate of the pure and mixed culture on nitrile substrate were determined with nonlinear regression of growth curves using GraphPad software, Prism version 6.

Biodegradation of nitriles by test organisms

Biodegradation of both glutaronitrile and benzonitrile in the media during the period of incubation was carried out using gas chromatography [Hewlett Packard (HP) 5890 series II (California, USA) with a flame ionization detection (FID)]. The GC column oven was operated with an initial temperature of 50 °C to 100 °C for 1 min. While operating conditions: an OV-3 glass column pack with internal diameter of 3.2 mm and length of 30 m packed with porapak N, 60/100, a column temperature: 220 °C, injector temperature: 200 °C, a detector temperature: 250 °C, flow rate: 450 mL/min with N₂ carrier gas and H₂ and temperature/ramping rate: 10 °C/min. A standard profile was first obtained with which the test sample was analyzed.

DNA extraction and nitrilase gene amplification

Jena Bioscience DNA preparation kits (Germany) were used for the extraction and purification of genomic DNA. Polymerase chain reaction was used for nitrilase gene amplification under standard conditions using the designed nitrilase-specific primer pair (Table 1). The following PCR program was used for the amplification of the DNA fragment: 5 min 94 °C followed by 30 cycles of 45 s 94 °C, 45 s 60 °C, 1 min 72 °C, and a final elongation of 10 min 72 °C. Millipore water (blank) was used as a negative control. The PCR product was gel purified and sequenced with an automated sequencer (ABI PRISM 377, PE Biosystems Inc.). BLAST (http://www.ncbi.nlm.nih.gov/) was used to find closely related nitrilase gene sequences.

Table 1 Nucleotide primers used for amplification of nitrilase gene

Results

Growth potentials of nitrile-metabolizing bacteria on nitriles

Bacillus sp. and Corynebacterium sp. had doubling times of 12.16 and 9.46 (µ = 0.082, 0.106) on glutaronitrile (single substrate) (Table 2), while doubling times of 7.40 and 7.75 (µ = 0.135, 0.129) were recorded for the mixed culture   on glutaronitrile (single substrate) and mixed substrates (glutaronitrile and benzonitrile) (Table 2). Similarly, Bacillus sp. and Corynebacterium sp. had doubling times of 11.11 and 10.00 (µ = 0.090, 0.100) on benzonitrile (single substrate), while doubling times of 8.09 and 8.71 (µ = 0.124, 0.115) were recorded for the mixed culture on benzonitrile (single substrate) and mixed substrates (Table 2). The results showed that the mixed cultures of the bacterial species had better growth in each of the nitrile compounds both as single and mixed forms (Table 2).

Table 2 Growth potentials of nitrile-metabolizing  bacteria species in form of pure  and mixed culture grown on Glutaronitrile and Benzonitrile

Biodegradation of nitriles by test organisms

The enzyme products formed during the degradation of nitriles were determined by gas chromatography (GC). The GC results revealed that strain WOD8 degraded glutaronitrile from the initial concentration of 128.75 gL^-1 to 35.77 gL^-1, while 15.54 gL^-1  of 4-cyanobutyric acid (4CBA) and 94.35 gL^-1  glutaric acids (GA) were obtained as enzyme products, though strain WOIS2 degraded 124.87 gL^-1 to 9.3 gL^-1  of glutaronitrile alongside the formation of 13.69 gL^-1  of 4-cyanobutyric acid (4CBA) and 118.59 gL^-1  of glutaric acid (GA) (Fig. 1). However, the mixed cultures degraded glutaronitrile from initial concentration of 116.89 gL^-1  to 13.40 gL^-1  and 10.04 gL^-1  of 4CBA and 86.38 gL^-1  of GA had accumulated  Finally, the  mixed culture degraded  glutaronitrile portion in the mixed substrates from initial concentration of 86.63 gL^-1, to 7.21 gL^-1 and  5.15 gL^-1 CBA had accumulated, while the same mixed culture degraded benzonitrile portion from initial concentration of 82.40 gL^-1, to 4.80 gL^-1 and 11.10 gL^-1 BA had formed.

Fig. 1

Degradation of glutaronitrile and benzonitrile by Bacillus sp. strain WOD8 and Corynebacterium sp. strain WOIS2. A Bacillus sp. strain WOD8 on glutaronitrile; B Corynebacterium sp. strain WOIS2 on glutaronitrile; C Bacillus sp. strain WOD8 on benzonitrile; D Corynebacterium sp. strain WOIS2 on benzonitrile

Furthermore, strain WOD8 cultured in mineral salts medium (MSM) containing benzonitrile used benzonitrile from an initial concentration of 128.99 gL^-1 to 27.39 gL^-1 and 101.44 gL^-1 benzoic acid was formed (Fig. 1) while strain WOIS2 degraded 127.75 gL^-1 to 13.79 gL^-1 and 120.97 gL^-1 benzoic acid (BA) was obtained (Fig. 1). The results of nitrile metabolism by the mixed cultures are presented in Fig. 2. The mixed cultures degraded benzonitrile from initial concentration of 121.98 gL^-1 to 10.42 gL⁻¹ and 90.01 gL^-1 of BA had accumulated.

Fig. 2

Degradation of glutaronitrile and benzonitrile by mixed cultures in the culture fluid. A Glut-Glutaronitrile. B Benzonitrile, 4-CBA-4-cyanobutyric acid, GA-Glutaric acid, Benz-Benzonitrile and BA-Benzoic acid

Whereas on the mixed substrates, the mixed culture degraded 86.63 gL^-1  to 7.21 gL^-1 and 5.15 gL^-1 4-CBA had accumulated while initial concentration of benzonitrile of 82.40 gL^-1 was degraded to 4.80 gL^-1 and 11.10 gL^-1 of BA had accumulated. The results indicated that we had reached 88.5% biodegradation of glutaronitrile and 91.5% for benzonitrile (Fig. 2).

Metabolic pathway of assimilation of glutaronitrile and benzonitrile by test organisms

From the investigations carried out, the metabolic pathway for the assimilation of nitrile compounds was elucidated in Corynebacterium sp. strain WOIS2 and Bacillus sp. strain WOD8.

Glutaronitrile was metabolized into 4-cyanobutyric acid and glutaric acid through the monoenzymatic pathway, while benzonitrile was similarly metabolized into benzoic acid just through the monoenzymatic pathway (Fig. 3). Considering the biodegradation investigation, the proposed monoenzymatic pathway was followed by strains in the generation of enzyme products from glutaronitrile and benzonitrile (Fig. 3).

Fig. 3

Proposed pathway for the degradation of Glutaronitrile (A) and Benzonitrile (B) by Corynebacterium sp. strain WOIS2 and Bacillus sp. strain WOD8

The culture broth tested positive for ammonia, which further confirmed the breakdown of nitrile compounds catalytically acted upon by nitrilase from the test organisms.

Nitrilase gene and evolutionary relatedness

Upon amplification, band sizes of 1400 bp and 1000 bp were obtained from nitrilases from strains WOD8 and WOIS2, respectively (Fig. 4). The extra domain gained by the nitrilase gene from strain WOD8 caused a sharp difference in the expected band sizes. The nitrilase gene sequences have been submitted to the National Center for Biotechnology Information (NCBI) and have been assigned MG993210 and MG993211 as accession numbers (Table 3).

Fig. 4

Amplification of the DNA sequence encoding nitrilase. Lane 1—DL2000 molecular marker; lane 2—nitrilase gene from strainWOIS2; lane 3—millipore water negative control; lane 4—nitrilase gene from strain WOD8

Table 3 Genotypic identities of nitrilases from test bacterial isolates

MEGA version 5 was used for phylogenetic and molecular evolutionary analyses (Tamura et al. 2007). The neighbor-joining evolutionary model was chosen for phylogenetic tree construction. The homology search showed that the nitrilase gene of Bacillus sp. strain WOD8 and Corynebacterium sp. WOIS2 both had 97% similarity to nitrilase gene of  Bacillus pumilus strain 8A3 AF492814 and Bacillus safensis strain U41 EU713463, respectively  (Fig. 5; Table 3).

Fig. 5

Phylogenetic tree of nitrilase and cyanide dihydratase sequences (using Mega software version 5). The following sequences with their relevant NCBI registration numbers were used. The sequences were aligned by using the program CLUSTAL W (version 1.8), the dendrograms calculated by bootstrap neighbor joining, and the phylogenetic tree drawn

Discussion

This investigation shows the main findings on nitrile metabolic potentials and nitrilase gene discovery in test species isolated from leachates in solid waste in Lagos, Nigeria.

Additionally, the gene responsible for nitrilase production in Bacillus sp. and Corynebacterium sp. were amplified and sequenced. Nitrilases with degradation potential that degraded nitriles to corresponding carboxylic acid and ammonia have been characterized (Gong et al. 2012; Thimann et al. 1964; Hook and Robinson 1964; Harper 1977a, b).

In this context, there are several reports on the metabolism of nitriles in the form of aliphatic and aromatic nitrile compounds. Numerous microorganisms, especially bacteria, have been reported to degrade both aliphatic and aromatic nitriles in the literature, and a few of these are Arthrobacter sp. I-9 (Yamada et al. 1980), Bacillus pallidus (Cramp et al. 1997), Mucolate Actinomycetes (Brandao and Bull 2003), Microbacterium Imperiale CBS 498-74 (Cantarella et al. 2006), Klebsiella oxytoca (Kao et al. 2006), Cryptococcus sp. UFMG-Y28 (Rezende et al. 2000), Bacillus sp. UG-5B (Ludmila et al. 2008), Isoptericola variabilis RGT01 (Gurdeep et al. 2014), Klebsiella sp. (Nawaz et al. 1992). Acidovorax sp. (Chen et al. 2009). Acidovorax facilis 72W (Hann et al. 2003).

The substrate choices of nitrilase produced by different organisms were discovered to be diverse. R. rhodochrous K22, for example, hydrolyzes aliphatic nitriles, but the nitrile concentration was very low (0.2 mmol/L). Similarly, Bacillus pallidus nitrilase hydrolyzed aliphatic, aromatic, and heterocyclic nitriles (Dennett and Blamey 2016), whereas Acidovorax sp. SK1 had a substrate selectivity for mandelonitrile as well as 4-methoxy, 2-nitrobenzonitrile. In the present study, the strains displayed wide specificities for both aliphatic and aromatic nitriles.

In this work, glutaronitrile was metabolized to 4-cyanobutyric acid and glutaric acid through the monoenzymatic pathway, while benzonitrile was relatively metabolized to benzoic acid only through the monoenzymatic pathway. The results from this investigation showed that glutaronitrile and benzonitrile were degraded to enzyme products by nitrilases obtained from strains WOD8 and WOIS2, respectively. However, glutaronitrile was preferably degraded over benzonitrile.

Therefore, the fundamental analysis of nitrile degradation at the protein and gene levels could lead to biological environmental improvement.

According to Kiziak et al. (2005), nitrilase obtained from Alcaligenes faecalis JM3 has been described as arylacetonitrilase, simplifying its substrate specification, and it appeared to be acceptable and considered an accomplishment to also group the nitrilase obtained from Corynebacterium sp. strain WOIS2 and Bacillus sp. strain WOD8 in this study as glutaronitrilase. Along these lines, there were no strong connections between the enzymic action and the size or polarity of the substituents (Kiziak et al. 2005).

This was an unexpected observation because it has been previously suggested that enrichments with specific nitriles usually result in the isolation of bacteria with nitrile hydrolyzing enzyme systems demonstrating high activities toward the nitriles used as enrichment substrates (Layh et al. 1997). Kiziak et al. (2005) reported that nitrilase enzyme from Pseudomonas fluorescens EBC191 nitrilase validated a strong priority and best interest for valeronitrile as substrate out of all the tested aliphatic nitriles, which has a specific activity of approximately 4 U mg-1 The occurrence and location of the aromatic ring with the sort of alkyl side chain is a key factor which distinguishes suitable substrates.

Strains WOD8 and WOIS2 degraded glutaronitrile at degradation rates of 72.2% and 92.6%, respectively. The mixed cultures of strains WOD8 and WOIS2 degraded glutaronitrile at 88.5%. However, WOD8 and WOIS2 degraded benzonitrile at 78.8% and 89.2%, respectively. However, cocultures of two (2) strains degraded benzonitrile at 91.5%. This high percentage of nitrile degradation, as observed when using the mixed cultures of the two studied bacteria, can certainly be considered one of the findings of this study.

The nitrilases obtained from Bacillus sp. strain OxB‐1 (Kato et al. 2000), A. faecalis JM3 (Kobayashi et al. 1993), C. testosteroni (Layh et al. 1997), and R. rhodochrous strains K22 and J1 (Kato et al. 2000; Kobayashi et al. 1993) have been sequenced. The bacterial nitrilases show remarkably less conservation inside the group. Approximately 53% homology was recorded between the aliphatic nitrilases of C. testosteroni (Levy-Schil et al. 1995) and Bacillus sp. strain OxB‐1 nitrilase, which is linked with aldoxime degradation (Kobayashi et al. 1992a). The base sequence of 957 bp from the nitrilase gene fragment from soil samples as shown by Riffani et al. (2015) and Kobayashi et al. (1992b), has high similarity with Rhodococcus rhodochrous strain tg1-A6 nitrilase. Asano and Kato (1998) found identical nitrilase genes in various bacterial strains and real-time PCR detection of the genes in soils demonstrates horizontal gene transfer. They discovered that bacterial enzymes that can hydrolyze nitrile have a lot of industrial potential.

Similarly, in the present study, band size values of 1400 and 1000 bp were obtained by nitrilases from strains WOIS2 and WOD8 and showed a high similarity to other nitrilases recently described. It was of remarkable interest that there was a contrast in the band sizes of the PCR products from the two strains isolated in this study, which might be caused by the domain acquired by the nitrilase gene from strain WOD8.

The results of this present study has led to a knowledge-based study of nitrile-degrading organisms, setting the stage for comparative genomics between Nigeria's nitrilase-producing organisms and their counterparts from other industrialized nations of the world. Likewise, this work revealed that in tropical environments, nitrilase-producing Bacillus sp. and Corynebacterium sp. that showed biodegradative capabilities for the degradation of nitrile. Therefore, these strains may be prospecting biological agents for the detoxifying of nitrile-based wastes from polluted environments.

A further investigation of these bacteria nitrilases for the large-scale bioremediation of nitrile compound is suggested.

Conclusions

In our opinion, the outcome of this study and an account of the various capabilities of these cultures (pure and mixed form) is a strong pointer that these tropical nitrile-metabolizing bacteria isolated from solid waste leachates in Lagos may be promising tools to control nitrile pollution as well as cyanogenic glucosides from polluted environments. Hence, nitrile-metabolizing bacteria are worth further pursuits for biotechnological purposes.
