Insecticidal efficacy of nano zeolite against Tribolium confusum (Col., Tenebrionidae) and Callosobruchus maculatus (Col., Bruchidae)

Abstract

Background

Stored-product insect pests are responsible for considerable quantitative and qualitative losses of agricultural products mainly cereals and legumes. The confused flour beetle Tribolium confusum and the cowpea weevil Callosobruchus maculatus are considered as the most destructive pests of stored grains and grain-derived products. In the present study nano zeolite (40–50 nm) was applied at different dose rates to wheat and cowpea to evaluate its insecticidal efficacy against both insects.

Results

Insect mortality was assessed after 1, 2, 3, 7, and 14 days of exposure for T. confusum and after 1, 2, and 3 days of exposure for C. maculatus. The mortality of T. confusum and C. maculatus adults exposed to wheat and cowpea seeds treated with nano zeolite was increased significantly with increasing dose and exposure intervals. The adult progeny production and the number of eggs laid were significantly decreased by increasing nano zeolite dose. In the present study, scanning electron microscope (SEM) was used to observe the adult insects exposed to nano zeolite-treated seeds. Nano zeolite attached all over the insect body with scratches and splits on the cuticle that lead to the loss of water through dehydration.

Conclusion

The results indicated that nano zeolite, which is considered as nontoxic to the environment and safe for human consumption, can be used effectively with success as an integral part of programs for the protection of cereal grains from stored-product insect pests.

Background

Stored-product insect pests are responsible for considerable quantitative and qualitative losses of agricultural products mainly cereals and legumes (Phillips and Throne 2010). The confused flour beetle Tribolium confusum Jacquelin du Val (Col., Tenebrionidae) is considered as the most destructive secondary pest of stored grains and grain-derived products. The pest causes damage ranging from 5 to 30% of the world’s total agricultural production (Mohammed 2013). Both larvae and adults are causing damage particularly to broken or damaged grains. The cowpea weevil, Callosobruchus maculatus F. (Col., Bruchidae), is one of the major pest of many stored products such as cowpea, chickpea, green gram, black gram, red gram, lentil, and soya bean (Edde and Amatobi 2003). The development of a single larva in a grain can lead to weight losses of 8 to 22% (Credland et al. 1986).

Current control methods for these two pests are mainly based on the use of synthetic insecticides and fumigants which resulted in the development of resistance to commonly used grain protectants and fumigants (Tay et al. 2016) thus there is an urgent need to apply an eco-friendly, safe and low-cost alternative for the chemical pesticides to protect the stored grains and seeds against these insect pests.

Non-toxic materials such as inert dusts have become an essential element in programs of integrated pest management. Zeolites are microporous, chemically inactive aluminosilicate minerals that found in nature and, like diatomaceous earth, it belongs to the group of inert dusts that contain natural silica (Subramanyam and Roesli 2000; Payra and Dutta 2003). Currently, there are several types of zeolites; among natural zeolites, the most studied mineral is clinoptilolite. Zeolites are used as soil amendments for the enhancement of soil physical properties (Ramesh and Reddy 2011), as fertilizer carriers that permit slow nutrient release (Rehakova et al. 2004) and as animal feed additive (Wu et al. 2013). Natural zeolite is considered non-toxic and safe for human consumption (International Agency for Research on Cancer IARC 1997a, b). Moreover, it has been listed by Codex Alimentarius Commission (1999) as granted substance in organic food production and in plant protection. These advantages have expanded zeolite applications in agricultural field. Nanomaterials (having particles with one or more dimensions ≤ 100 nm) possess distinctive characteristics, size-dependent qualities, and high surface-to-volume ratio thus making them hold great promise in plant protection and nutrition (Ghormade et al. 2011). There are few available studies related to insecticidal efficacy of zeolite in the nano range against stored-product insect pests, however studying zeolite against stored products with special stress on coleopteran insects, have attracted the attention of previous authors notably Kljajic et al. (2010) against Rhyzopertha dominica, Tribolium castaneum, and Sitophilus oryzae, Rumbos et al. (2016) against S. oryzae, T. confusum, and Oryzaephilus surinamensis in wheat and (Lu et al. 2017) against C. maculatus adults who investigated the insecticidal effect of the natural and modified zeolites and reported that mortality levels reached 90% and 100% after 21 days of exposure to cowpea seeds treated with different concentrations. The insecticidal activity of two natural zeolite formulations (Zeocem and Mycostop) were investigated against S. oryzae and O. surinamensis on wheat (Eroglu et al. 2019) their results indicated that 100% mortality resulted only after Zeocem treatment of O. surinamensis and progeny production was very low. While the mortality was only 87% for S. oryzae and progeny production was high.

The objective of the present study is to investigate the insecticidal effect of nano zeolite against adults of T. confusum and C. maculatus in addition to study their effect on the progeny production and development of the tested pests, subsequently evaluating the role of nano zeolite that can minimize or even exclude the use of toxic insecticides in pest control and encourage the use of natural inert dust in programs of integrated pest management (IPM).

Methods

Tested insects

The adults of T. confusum and C. maculatus were reared for several generations for 1 year in laboratory of Pests and Plant Protection Department, National Research Centre (NRC) on soft wheat flour plus 5% brewer’s yeast (by weight) and cowpea seeds respectively in glass jars (10 × 9 × 18 cm) and covered with fine muslin cloth for ventilation. The two insect species were kept under controlled laboratory conditions at 30 ± 2 °C and 65 ± 5% RH in continuous darkness. T. confusum and C. maculatus adults used in experiments were > 7 and > 3 days old respectively.

Commodity

Soft wheat flour, cowpea seeds, and wheat grains used for insect feeding and biological bioassays were purchased from a local market and stored at − 4 °C for at least 5 days before being used in order to kill any live insects present in the products.

Zeolite nanoparticles

Nano zeolite material used in the experiments was purchased from NanoTech Egypt for Photo-Electronics. The product formula is [Na₂Al₂Si₃O₁₀·2H₂O] and synthesized by ball milling machine with physical properties illustrated in Table 1. For size and shape characterizations, transmission electron microscope (TEM) performed on JEOL JEM-2100 high-resolution TEM at an accelerating voltage of 200 kV, the obtained images from NanoTech, Egypt, show the sheet-like shape of nano zeolite with 40–45 nm average size (Fig. 1).

Table 1 Physical properties of nano zeolite used in the experiments

Fig. 1

TEM micrograph of nano zeolite

Bioassay

Toxicity bioassay

In this bioassay, the insecticidal efficacy of nano zeolite (40–45 nm) was assessed against T. confusum and C. maculatus adults in wheat and cowpea seeds respectively. For T. confusum, broken wheat grains mixed with nano zeolite powder at different doses (250, 500, 600, 700, and 800 ppm) in the rate of (10 mg/40 g, 20 mg/40 g, 24 mg/40 g, 28 mg/40 g, and 32 mg/40 g) respectively. While for C. maculatus, seeds of cowpea mixed with nano zeolite dust at doses of (100, 200, 300, 400, and 500 ppm) in the rate of (4 mg/40 g, 8 mg/40 g, 12 mg/40 g, 16 mg/40 g, and 20 mg/40 g) respectively. Wheat grains and cowpea seeds mixed with selected doses of nano zeolite dust in separate small plastic vessels (300 ml) covered with fine muslin cloth for ventilation. To achieve equal distribution of nano zeolite, the vessels were shaken manually for approximately 2 min, another group served as control supplied with untreated wheat grains and cowpea seeds (without nano zeolite dust). Five replicates were carried out for each treatment as well as for the control group, and each replicate contained 20 adults of T. confusum with 40 g of broken wheat grains and 20 adults of C. maculatus with 40 g of cowpea seeds. All vessels were kept at 30 ± 2 °C and 65 ± 5% RH in continuous darkness.

Insect mortality was determined after 1, 2, 3, 7, and 14 days of exposure for T. confusum and after 1, 2, and 3 days of exposure for C. maculatus. Doses-mortality% was recorded to calculate LD₅₀ values.

Biological efficacy

After the final mortality count of T. confusum has been recorded, all individuals dead and alive adults were removed from the plastic vessels, and then kept under the same previously mentioned controlled conditions for additional 30 days. After the termination of this interval, the number of emerged larvae in each vessel was recorded to determine insect progeny production in the F₁ generation. Inhibition rate percentage (IR%) was calculated as follows:

(Mean No. of individuals in control − Mean No. of individuals in treated)/Mean No. of individuals in control × 100.

The efficacy of nano zeolite on certain biological aspects of C. maculatus had been investigated. Cowpea seeds have been treated with selected doses of nano zeolite powder (100, 200, 300, 400, and 500 ppm) using the above-mentioned method, and then one-sexed pair of newly emerged adults of C. maculatus from the stock culture introduced in each vessel contained 40 g of cowpea seeds. The experiment was carried out in 10 replicates, and another group of paired sexed adults was subjected to untreated cowpea seeds and used as control. Both groups treated and non-treated were checked daily to record the longevity of males and females and to count the number of eggs laid by each female on the seeds. The mean percentage of adult emergence was also calculated as follows:

Mean % of emergence = No. of emerged adults/No. of laid eggs × 100.

SEM

The T. confusum and C. maculatus adults exposed to wheat grains and cowpea seeds treated with 225.5 and 74.7 ppm according to LD₅₀ of nano zeolite powders for 7 days and 3 days respectively were examined under scanning electron microscope. The treated dead adults after exposure to zeolite nanoparticles were allowed to air-dry for 5 days and then, without any other preparations for non-removal of nano zeolite from insects, were placed onto adhesive stubs and coated with gold to improve the imaging of the samples. Following that, insects were examined under low vacuum scanning electron microscope (SEM) (Jeol-JSM-5600 LV in SEM) in the Electronic Microscope Unite, Central Laboratory, National Research Centre, Cairo.

Data analysis

Values of LD₅₀ were calculated by using the Probit analysis method of (Finney 1971). The biological data were analyzed using one-way ANOVA. Significant differences between treatments were determined using Duncan’s test (P < 0.05). Data analyses were performed using SPSS version 14.0 (SPSS, Inc., Chicago, IL, USA).

Results

Toxicity and biological bioassays

Mortality and progeny production of T. confusum

Mortality of T. confusum adults was significantly affected by the exposure intervals and the dose of nano zeolite (40–45 nm). After 1, 2, and 3 days of exposure the adult mortality remained < 50% at all tested doses. The associated interactions for mortality levels of T. confusum adults were significantly high after 2 weeks of storage, with a mortality of 96.66% at the highest application rate (800 ppm) nano zeolite treatment. The recorded mortality was notably lower and less than 50% at 250 ppm, while on wheat treated with 600 and 500 ppm it increased to 80.23% and 66.66% after 14 days of exposure compared to the adult mortality in control group (5.21%) (Table 2).

Table 2 Effect of nano zeolite (40–45 nm) against T. confusum adults at different dose rates

Data presented in Table 3 illustrate that the emergence of T. confusum adults was remarkably affected in nano zeolite-treated wheat for all doses particularly at the dose 800 ppm, the progeny production counts were significantly very low and did not exceed 0.4 individulas/vessel with highest %inhibition rate reached 99.23%. Furthermore, at very low dose tested 250 ppm the %IR was significantly high 77.77% compared to the untreated group (52.2 individuals/vessel).

Table 3 Mean number (±SE) of progeny counts and inhibition rate (%) of T. confusum exposed for 14 days to wheat kernels treated with different nano zeolite dose rates

Mortality and biological aspects of C. maculatus

Regarding the sensitivity of C. maculatus toward the different doses of nano zeolite application after 1, 2, and 3 days intervals, data obtained in Table 4 show that mortality levels did not exceed 55% after 1 day of contact with the highest application rate (500 ppm). Three days post-application, mortality levels increased greatly and reached to 100% compared to untreated adults (2.00%) at the same exposure interval, whereas levels of mortality of C. maculatus adults ranged between 9 and 52%, 28.63–66.66%, and 44.59–88.33% after 1, 2, and 3 days of exposure to cowpea seeds treated with 100, 200, 300, and 400 ppm respectively.

Table 4 Effect of nano zeolite (40–45 nm) against C. maculatus adults at different dose rates

Considering the sensitivity of adults (male and female) of C. maculatus toward nano zeolite application evaluated in terms of adult longevity and female fecundity, it was observed that there was a significant correlation between male and female adults longevity and nano zeolite dose application. Data in Table 5 showed that the adults (male and female) exposed to cowpea seeds treated with nano zeolite at higher doses (500 and 400 ppm) were characterized with short life span and significantly lower fertility, treated females failed to produce more eggs and achieved high inhibition of reproduction (zero adult emergence for both doses). After exposure to 300 and 200 ppm doses, progeny production was very low, while progeny production increased slightly with 100 ppm dose where each treated female laid 10.7 eggs that produced only 3.7 emerged adults compared to untreated female (with 59.4 eggs and 56.1 emerged adults).

Table 5 Efficacy of nano zeolite on some biological aspects of C. maculatus adults at different dose rates

It was noticed that the toxicity in both insects increased by increasing nano zeolite dose. The calculated LD₅₀ value for nano zeolite against T. confusum and C. maculatus adults was 225.5081 and 74.7872 ppm respectively (Table 6).

Table 6 LD₅₀ value of nano zeolite against adults of T. confusum and C. maculatus

Scanning electron microscope

The adherence of nano zeolite to adults of T. confusum and C. maculatus was examined after both insects have been exposed to wheat and cowpea seeds treated by calculated LD₅₀ of zeolite nanoparticles (225.5081 and 74.7872 50 ppm respectively).

The image obtained from scanning electron microscopic examination of untreated T. confusum adults (Fig. 2a, b) was compared with the images of treated ones that showed the strong uptake and attachment of nano zeolite on the cuticle of T. confusum adults (Fig. 3a, b), particles of nano zeolite (40-45 nm) were homogenously distributed on the outer surface of the insect and aggregate between thorax and abdomen joints, in addition to the loss of insect legs compared with untrated adults.

Fig. 2

Scanning electron microscope images of Tribolium confusum adults exposed to untreated wheat. a Dorsal view. b Section of dorsal view

Fig. 3

Scanning electron microscope images of Tribolium confusum adults exposed to 225.5 ppm of nano zeolite treated wheat. a Dorsal view, particles of nano zeolite aggregate on insect surface and on leg joints (arrows). b Section of dorsal view, particles of nano zeolite aggregate between thorax and abdomen joints (arrow)

Similarly, the image of untreated C. maculatus adult shows that the insect is retaining its antennae and legs (Fig. 4a, b), contrarily to the obtained images of treated C. maculatus (Fig. 5a, b) showed that particles of nano zeolite adhered to all body parts and distributed on the insect head, thorax, abdomen, elytra and legs. The insect appeared lost its appendages. The obtained images revealed that the reduction of nano zeolite particle size could possibly increase dust uptake even further when particles applied to wheat kernels and cowpea seeds to control T. confusum and C. maculatus.

Fig. 4

Scanning electron microscope images of Callosobruchus maculatus adults exposed to untreated cowpea. a Dorsal view. b Section of dorsal view

Fig. 5

Scanning electron microscope images of Callosobruchus maculatus adults exposed to 74.7 ppm of nano zeolite treated cowpea. a Dorsal view, particles of nano zeolite aggregate on insect surface and on leg joints (arrow). b Section of dorsal view particles of nano zeolite aggregate between thorax and abdomen joints (arrow)

Discussion

Inert dusts, such as zeolite, are promising alternative to conventional chemical insecticides and have been extensively researched and used in practice due to their low mammalian toxicity and slight or no effect on quality products treated with commercially applicable concentrations (Korunic 1998; Andric et al. 2012).

An attempt was made in the present study to test the efficacy of nano zeolite (40–45 nm) to protect the wheat kernels and the cowpea seeds from the infestation of two stored product insect pests, T. confusum and C. maculatus. It was observed from the present study that significant differences were recorded in mortality levels of T. confusum adults caused by the small particles nano zeolite-treated wheat kernels and after 2 weeks of storage the mortality reached 96.66% with highest application rate (800 ppm).

Tribolium spp. are considered as the most tolerant species among storage insects to inert dusts such as diatomaceous earth (Athanassiou et al. 2011; Kljajic et al. 2010). Nevertheless, Vayias and Athanassiou (2004) indicated that T. confusum larvae were susceptible to diatomaceous earth and hence, despite the fact that adults are tolerant, control can be achieved through increased immature control. On the other hand, nano zeolite was more effective against C. maculatus exposed to treated cowpea seeds. There was 100% mortality when adults were exposed for 72 h to cowpea seeds treated with the highest dose (500 ppm) of nano zeolite. It was observed from the obtained results the seeds treated with nano zeolite significantly reduced adult longevity and inhibited the oviposition of C. maculatus adult females, with adverse negative effect on egg hatchability and subsequently the percentage of emergence was drastically reduced in the treated group. Reduced egg laying could be due to fewer insect surviving the nano zeolite treatment especially with low doses (100–300 ppm) and the mean number of C. maculatus emerged adults ranged from 0.2 to 3.7 compared to untreated group (56.1). the current study shows the particle size of nanoparticles (40–45 nm) is critical factor determines insecticidal effect for the adults and progeny in addition to the exposure intervals and the different doses used; Kljajic et al. (2010) reported that progeny suppression of S. oryzae and T. castaneum to be 80–95% on wheat treated with natural zeolite at 0.75 g/kg and concluded that suffering adults insects due to desiccation and spiracle blockage by the exposure of zeolite could be the cause for this reduced fecundity. This could have prevented the mating as the zeolite nanoparticles attach all over the body of adult insects, it was not only desiccation or blockage of spiracles, but also the surface enlargement of integument as a consequence of dehydration (Voigt et al. 2009). The damage could have occurred to the protective wax coat on the cuticle of insects, both by absorption of epicuticular lipids from insect’s exoskeleton causing excessive dehydration and abrasion (Debnath et al. 2011; Arumugam et al. 2016; Lu et al. 2017). The fine zeolite particles create micro-wounds which are analogous with particle size.

Efficacy of nano zeolite against T. confusum and C. maculatus varied depending on the dose rates, exposure intervals, and the particle size. Furthermore, it is reported that insecticidal efficacy of the dust becomes enhanced if the particles are finely divided. Physical characteristics of the seeds are also an important factor for the attachment of nanoparticles on their surface, in addition to insect species and their developmental stage (Fields and Korunic 2000). Bohinc et al. (2018) and Bohinc and Trdan (2017) revealed that certain factors which are typical for inert dusts such as temperature and relative humidity may influence the mortality of S. zeamais adults. Many studies have investigated the insecticidal efficiency of inert dusts such as zeolite and silica against stored-product insects, and some of them have examined the uptake of dust particles from the target insect pest. Nansen et al. (2007) used SEM image to examine the uptake of entostat, an electrostatically chargeable powder to adults of Oryzaephilus surinamensis. Stephou et al. (2012), by using fluorescence indicator, reported that the addition of DE increased the conidial attachment of the entomopathogenic fungus Beauveria bassiana (Balsamo) to the cuticle of S. oryzae and T. confusum adults, and showed that there are specific body areas with higher conidial concentrations. In the present study, scanning electron microscope (SEM) was used to observe the surface and morphology of insect adults of T. confusum and C. maculatus exposed to treated wheat kernels and cowpea seeds with nano zeolite; the images showed the attachment of nanoparticles all over the body of both insects with scratches and splits on the cuticle, adhered to all body parts including the head, thorax, abdomen, and elytra with lost legs and antennae. Joints, legs, and intersegmental areas were particularly suitable for particles deposition. This subsequently led to the loss of water through dehydration as reported by Rumbos et al. (2016).

Conclusion

In this study, the insecticidal effect of nano zeolite was evaluated. The obtained results revealed that nano zeolite can be used as a safe and low-cost nanocide to control T. confusum and C. maculatus adults and its efficacy varied depending on the dose rates and exposure intervals. Nano zeolite can be effectively replacing chemical insecticides to protect stored products. Further research is needed to investigate the effect of above-mentioned factors on the insecticidal efficacy of nano zeolite against stored-product insects.
