Probing the potentiality of the defoliator Cricula trifenestrata Helfer silk: a revisit

Abstract

Background

Transformation of pest to valuable product is considered to be a noteworthy innovation. This article explores the potentiality of wild silkworm Cricula trifenestrata Helfer for sustainable development towards human livelihoods.

Results

The innate characteristics of this silkworm with robust rearing capacity have bestowed various aspects of biomaterials with special context to diversification of wild silk products. Views on challenges, prospects and the enigma of converting a pest to beneficial product are also unraveled. Exploration on utmost utilization of raw silk, scope for varied byproduct from silk waste may contribute a ray of hope for income generation to the rural population.

Conclusion

With suitable plantation and congenial climatic conditions for rearing Cricula trifenestrata may serve as an alternative wild silk in contributing to the country’s wild raw silk production.

Background

Wild/Vanya silkworm confers to non-mulberry silkworm which comprises Antheraea mylitta, Antheraea proylei, Antheraea assamensis and Samia ricini which are commercially exploited in India. In other countries wild silkworms which are commercially exploited includes Gonometa, Hylaphora, Antheraea yamamai, Antheraea pernyi etc. In the present scenario, India’s vanya raw silk production is around 10,581 MT (29.5%) against the country’s total production of 35,820 MT for the year 2019–20. In 2020–21, despite of covid-19 pandemic 33,739 MT of Raw silk was produced in which 9879 MT (29.2%) is contributed by vanya silk (Source Central Silk Board, Bangalore, India). There are numerous wild silkworm in India, which are least concerned for its probable productivity. An attempt is made to discuss about a common pest which can be transformed into a commercial product with scientific and technological intervention.

Cricula trifenestrata Helfer is a wild Lepidopteron sericigenous moth known for its lustrous golden cocoon. The Genus Cricula was proposed by Walker in 1855. Capt. Jenkins and Helfer coined the species trifenestrata due to the presence of 3 windows like structure in the forewing as represented in Fig. 1 (Tikader et al. 2014; Kaleka et al. 2018). It is invariably considered as a pest for Antherea assamensis i.e., muga silkworm as it depletes the foliage by feeding thereby affecting the Effective Rearing Rate (ERR) of Muga silkworm. They infect a wide range of host plants namely Mangifere indica, Persea bomycina, Anacardium occcidentale, Arachis hypogeal Cinnamomum cassia, litchi cheinensis, Machilus odoratissima and Camellia sinensis (Ahmed et al 2012; Gharde and Chaudhuri 2018; Narang and Gupta 1979; Tikader et al. 2014). Host diversity of Cricula trifenestrata is detailed in (Table 1). Cricula trifenestarata is widely distributed in South Asian countries (Fig. 2). Cricula trifenestrata is reported to be predominant in India, Andaman, Myanmar, Vietnam, Cambodia, Malaysia, Singapore, Thailand, Bangladesh, Java, Philippines countries (Tikader et al. 2014; UK 2014).

Fig. 1
figure 1

Cricula trifenestrata moth and Cocoon

Table 1 Host plant diversification of Cricula trifenestrata
Fig. 2
figure 2

Source: https://www.inaturalist.org/taxa/510228-Cricula-trifenestrata

Global distribution of Cricula trifenestrata.

Cricula trifenestrata takes up to 61–125 days to complete the life cycle. Complete defoliation occurs in 4th and 5th instar. The larvae have 5 instars and passes 4 generation in a year (Tikader 2012; Huq et al. 1991). The average fecundity was reported to be 141.7 ± 11.79, and observed hatching rate was 88.81 ± 1.37% when reared in Mangifera indica. The average Mangifera leaf consumption was about 29.4 g (Amin et al. 2008) Persea bombycina fed larvae (Figs. 3, 4) exhibited higher content of protein and lipid in the haemolymph suggesting Persea bombycina as the superior host in respect to silk deposition (Ghosh et al. 2015). High Infestation in Persea bombycina was observed during September to January (Ahmed et al. 2012). The efficiency of conversion of digested food in first instar when fed with Persea bombycina was 36.54% and the digestability was 67.74% indicating Persea bombycina as the preferred host plant by Cricula on the basis of nutritional indices. (Biswas et al. 2013). Cricula trifenestrata were even recorded, at an altitude of 1097 m in some parts of Tamilnadu (Singh 1992). In cashew, Cricula trifenestrata larval infestation had a positive correlation with number of flower and seeds (Siswanti et al. 2017).

Fig. 3
figure 3

Cricula trifenestrata infestation on Persea bombycina foliage

Fig. 4
figure 4

Different stages of Cricula trifenestrata larval infestation in Persea bombycina host

In Sikkim, Cricula was reported infesting Cardamom i.e., Amomum subulatum causing huge devastation of the crop. The average fecundity was observed to be 157–252 eggs per month. The mature larvae is black-brown with red sublateral stripes, 2–11 somites with six setiferous tuburcles. Larval period ranges to 87.16 + 2.65 days and larval mortality 23.23%. Life cycle takes around 168.92 days (Yadav and Kumar 2004). The chromosome number (n) of C. trifenestrata was found to be 31 (Narang and Gupta 1979). The cytochrome C oxidase subunit gene of Cricula trifenestrata was studied to identify specific unique sites for species identification to develop species marker. It was noted that 595 nucleotides are conserved in the species of cytochrome C oxidase gene. The 107th amino acid (valine) and 138th (threonine) were diagnostics amino acid for C. trifenestrata. The phylogentic study revealed that Cricula and Antherea share the same node of the saturnidae family suggesting monophyletic (Solihin et al. 2012).

Control measures

The Cricula infestation causes havoc destruction to the foliage hence researchers have studied various physical, chemical and biological control methods to prevent infestation in field crops. Proper weeding of the tree cover in summer is seen effective to prevent to Cricula larval infestation in Cinchona plantations. This cultural operation serves as a first line of physical defence in preventing infestation (Van Zwet 1950). Biological control by utilizing parasitoid serves as an effective control measure in controlling the Cricula (Table 2). Parasitizaton of Cricula trifenestrata eggs with Telenomus sp has complete efficacy up to pupal stages of. Cricula trifenestrata, when parasitized with Brachymeria criculae efficacy resulted in 79.71%. Mesomys orientalis and Sarcophaga sp. parasitoid can also control the Cricula infestation during pupal stage (Ali and Karim 1991). Xanthopimpla konowi parasitizes the pupae (Singh 1992). Brachymeria tibialis (Walker) parasitoid destroys and consumes the pupae inside the cocoon preventing future multiplication. Hence Brachymeria tibialis can be efficiently utilized as a biological control in Antherea assamensis silkworm rearing (Tikader 2012).

Table 2 Reported Biological control of Cricula trifenestrata at different stages of rearing

In Indonesia, Beauveria bassiana at a concentration of 5 × 106 spores suspension resulted in highest mortality of Cricula moth. However it is not effective in Antherea assamensis field (Sjafaruddin and Rahmatia 1999). Parasitoid Blepharipa zebina infest larvae of Cricula trifenestrata which infest Machilus bombycina (Negi et al. 1993). In Arunachal Pradesh Exorista sorbillans was observed as an endoparasitoid parasitizing the Cricula larvae and causing death at pupal stage during March to mid-September (Sarma et al. 2006). Chalcis cricula and C. etiplaeae parasitises Cricula larvae (Yadav and Kumar 2004).

Fenvalerate and cypermethrin were the most effective chemical control methods, when treated for 7 days post treatment resulted in 94.44 and 79.16% larval mortality (Munaan 1986). In Maharastra field study has resulted in effective control of Cricula infestation in ground nut by cyhalothrin and Naled at 0.0005 and 0.001% (Deshmukh 1992) chemically infestation can be controlled by endosulphan, deltamethrin and neem based pesticide like azadirachtin (0.003% and 0.015%) has been effective (Ahmed et al. 2012) 0.05% endosulfan and parathion-methyl was used to control (Singh 1992). 0.1% methyl parathion and endosulphan are effective chemical control methods reported (Yadav and Kumar 2004).

Methods

The rearing parameters are reported in varied host plants. Here attempts on exploration of post cocoon parameters are explored for commercial utilization. Cocoons of Cricula trifenestrata which was reared upon consuming Persea bombycinia in the wild were obtained and the pupal and shell weight was determined. The cocoons were stifled in hot air oven at 45 °C for 2 h. Owing to the presence of perforations in the cocoons reeling isa constrain hence it is utilized for spun yarn.

Degumming and cake preparation

The removal of sericin and letting the fibres loose for further processing is called Degumming. Cocoons of Cricula trifenestrata were degummed by boiling in 0.5% sodium carbonate for 45 min. Further rinsing in hot distilled water and distilled cold water. Drying was done in hot air oven at 45 °C for 2 h.

$${\text{Degumming}}\,{\text{loss}}\,{\text{(\%)}} = W_{1} - W_{2} /W_{1}$$

where W1 is the initial weight of conditioned Cricula cocoons samples and W2 is the weight of degummed as well as conditioned Cricula cocoons sample Followed by washing. The individual degummed cocoons were opened in water and sheets are formed and placed overlapping. Cakes were prepared by overlapping 3–4 cocoon fibre sheets and dried in room temperature (Munshi et al. 2016).

Spinning

The yarn is spin in a motorized spinning machine. The silk ratio and silk recovery is determined.

Results

145 cocoons were obtained from the wild (Fig. 5). The post cocoon parameters were observed and analyzed and the results are shown in Table 3.

Fig. 5
figure 5

a Spinned cocoons in leaves, b collected cocoons reared on Persea bombycina, c single cocoon and pupae, d matured pupa

Table 3 Post cocoon parameters determined in Cricula trifenestrata cocoon

The total cocoon weight was observed to be 105 gm. wherein total shell weight was 15.5 gm and total pupal weight was 89.5 gm. Single coccon weight, single shell weight and single pupal weight was 0.72 gm, 0.106 gm and 0.617 gm respectively. The silk ratio % was 14.76%. Shell weight after degumming was 14.5 gm. The Degumming loss (%) was found to be 6.45%. The spun yarn weight was found to be 9.8 gm. and silk waste was 4.7 gm. Thereby determining that the silk recovery % was 67.59% and Silk waste % was 32.41%.

Discussion

Exploring the insights of commercial utilization of Cricula silk

The cocoons were oval with tapering ends and contain perforation on the surface. When the cocoons were subjected to degumming the golden lusture was lost implying the affinity of the golden hue was high in the sericin content and not fibroin. Insights on developing an efficient degumming agent which aids in retaining the golden hue in the yarn may result in high demand of the fabric. The silk recovery % was observed to be higher than muga which was conventionally around 40–48% and higher yield was 55% in Muga silk.

Cricula trifenestrata fibre was reported for the tensile strength and biocompatibility. The modulus elasticity of the single fiber of Cricula trifenestrata is about 3681 MPa. The silk can be prepared by degumming method of boiling in 0.01 M NaOH for 1 h. Degumming above the concentration 0.01 M NaOH resulted in hydrolysis of fibre. The ultimate tensile strength is obtained about 162 MPa together with value of failure strain about 0.12 (Nindhia et al. 2014).

Unlike Bombyx mori, the pigments are usually deposited in the sericin which gets washed off during degumming process. However when cricula cocoons were degummed with chymotrypsin and the pigment content was observed in fibroin and sericin. It was observed that 1.4 times higher fold the pigment is present in fibroin than sericin (Yamada et al. 2001).

The wild silks in the world are still unexplored for their potential commercial utilization. Previous studies affirm the merits of Cricula silk for instance; C. trifenestrata silk protein was isolated and studied. The molecular mass of sericin and fibroin were 400 kDa and 350 kDa respectively, however fibroin when later underwent reduction the molecular mass was 180 kDa. The amino acid constituents resembled with higher serine content (Yamada and Tsubouchi 2001) The polar and non polar amino acid ratio in cricula sericin was about 69:31 (Manesa et al. 2020). Cricula trifenestrata Sericin has anti-proliferative activity in feline kidney cells and Sericin-induced apoptosis (Liu et al. 2016). Cricula trifenestrata cocoon extract when treated on human fibroblasts revealed non cytotoxicty (Sunarintyas et al. 2012).

This study affirms the efficacy of Cricula to be utilized as a spun silk (Fig. 6). The golden cocoons are utilized as artifacts for attractive aesthetic products.

Fig. 6
figure 6

a Degummed cocoon, b the yarn is spun in motorized spinning machine, c Spun yarn hank preparation on approvate, d cricula spun yarn

Conclusions

Popularization on the artistic utilization of these golden cocoons in fabric designing or any other products may be of high demand in the near future. In the current surge, Cricula sericin also has added biological effects in pharmaceuticals and cosmecutical industry. Hence more insights are to be explored for commercial product utilization of Cricula silk as a potential biomaterial, fabric, pharmaceutical, food, cosmetics and fuel industry.

Availability of data and material

All data generated or analyzed during this study are included in this manuscript.

Abbreviations

MT:

Metric ton

NaOH:

Sodium hydroxide

kDa:

Kilo dalton

MPa:

Mega pascal

References

  1. Ahmed SA, Dutta LC, Sarmah MC (2012) Bio-efficacy of some insecticides against leaf eating caterpillar, Cricula trifenestrata Helfer (Lepidoptera: Saturniidae) Infesting Som, Persea bombycina Kost. Plantation Acad J Entomol 5(2):94–98

    CAS  Google Scholar

  2. Alam MZ, Ahmed F (1992) Parasitoids associated with different stages of Cricula trifenestrata Helfer. Lepidoptera, Saturniidae

    Google Scholar

  3. Ali MI, Karim MA (1991) Notes on the biology, behaviour and biocontrol agents of mango defoliator Cricula trifenestrata (Lepidoptera: Saturniidae). Bangl J Entomol 1:83–87

    Google Scholar

  4. Amin MR, Ahad MA, Rono MMA, Tithi DA (2008) Life history traits of Cricula trifenestrata (Lepidoptera: Saturniidae) feeding on Mangifera indica. J Agrofor Environ 2(1):1–6

    Google Scholar

  5. Biswas S, Hath TK, Ray N (2013) Effect of different host plants on nutritional indices of wild silk moth. Cricula Trifenestrata J Entomol Res 37(3):223–227

    Google Scholar

  6. Deshmukh PB (1992) Efficacy of two insecticide treatments against aphid, Toxoptera avrantii, and caterpillar, Circula trifenesirata, on groundnut, Arachis hypogea L. Int Pest Control 34(5):153

    CAS  Google Scholar

  7. Gharde SK, Chaudhuri N (2018) The life history and population growth parameters of leaf eating caterpillar Cricula trifenestrata Helfer (Lepidoptera: Saturniidae) infesting manochilus bombycina king. Int J Curr Microbiol App Sci 7(2):710–717

    Article  Google Scholar

  8. Ghosh J, Chaudhuri N, Bera C (2015) Bio-ecological analysis to identify the critical stage of development of mango defoliator Cricula trifenestrata (Lepidoptera: Saturniidae). Int J Recent Sci Res 6(10):7259–7262

    Google Scholar

  9. Huq SB, Hossain M, Khan AB (1991) Biology of Cricula trifenestrata (Lepidoptera: Saturniidae), a leaf eating caterpillar of mango. Bangl J Entomol 1:19–26

    Google Scholar

  10. Kaleka AS, Singh D, Saini S (2018) Further studies on the moth Cricula trifenestrata from North-West India (Lepidoptera: Saturniidae). Ann Entomol 20(1):15–17

    Google Scholar

  11. Liu W, Karimazawa M, Ozaki T, An Y, Miyazaki M, Suzuki K, Tsutsumi KI, Yamashita T (2016) Cell proliferation inhibition by sericin from the wild silkworm. Cricula Trifenestrata Adv Biol Chem 6(1):28–33

    Article  Google Scholar

  12. Manesa KC, Kebede TG, Dube S, Nindi MM (2020) Profiling of Silk Sericin from cocoons of three Southern African Wild silk moths with a focus on their antimicrobial and antioxidant properties. Materials 13(24):5706

    ADS  Article  CAS  Google Scholar

  13. Munaan A (1986) Controlling Cricula trifenestrata Helf. on cashew trees. Pemberitaan Penelitian Tanaman Industri 12(1–2):36–40

    Google Scholar

  14. Munshi R, Mazumdar S, Gupta PD, Chattopadhyay D (2016) Studies on standardization on degumming process for different eco races of eri silk cocoons. Indian J Nat Fibres 3(1):69–76

    Google Scholar

  15. Narang RC, Gupta ML (1979) Chromosome number of Cricula trifenestrata Helfer (Lepidoptera: Saturniidae). Curr Sci 48(10):465–466

    Google Scholar

  16. Negi BK, Barah A, Siddiqui AA, Sengupta AK (1993) Cricula trifenestrata (Lepidoptera: Saturniidae)-a new alternate host of Blepharipa zebina (Diptera: Tachinidae). In: Recent advances in Uzi fly research: proceedings of the national seminar on Uzi fly and its control, 16–17 January, 1992. Karnataka State Sericulture Development Institute, pp 269–271.

  17. Nindhia TGT, Knejzlik Z, Ruml T, Nindhia TS (2014) Tensile properties and biocompatibility of indonesian wild silk Cricula trifenestrata: a preliminary study. J Med Bioeng 3(2):140–143

    Google Scholar

  18. Sarma AK, Gupta MK, Singh KM (2006) New record of a dipteran endoparasitoid of Cricula trifenestrata Helfer on Som Machilus Bombycina. J Plant Protect Environ 3(1):143–144

    Google Scholar

  19. Singh SP (1992) Frequent outbreaks of Cricula trifenestrata Helfer (Lepidoptera, Saturniidae) on mango. Indian J Plant Protect 20(1):114–115

    Google Scholar

  20. Siswanti R, Supriyadi S, Subagiya S (2017) Correlation between damage plant by silkworm Cricula trifenestrata to cashew yield. Agrotechnol Res J 1(1):21–27

    Article  Google Scholar

  21. Sjafaruddin M, Rahmatia D (1999) Field trial of Beauveria bassiana to canarium moth (Cricula trifenestrata) on cashew crop. In: Seminar Nasional Hasil Pengkajian dan Penelitian Teknologi Pertanian Menghadapi Era Otonomi Daerah, Palu (Indonesia), 3–4 Nov 1999. PSE.

  22. Solihin DD, Noor RR, Thohari AM (2012) The characteristics of cytochrome C oxidase gene subunit I in wild silkmoth Cricula trifenestrata helfer and its evaluation for species marker. Media Peternakan 35(2):102–102

    Article  Google Scholar

  23. Sunarintyas S, Siswomihardjo W, Tontowi AE (2012) Cytotoxicity of Cricula triphenestrata cocoon extract on human fibroblasts. Int J Biomater 2012:222–226

    Article  Google Scholar

  24. Tikader A (2012) New record of Brachymeria tibialis (Walker)(Hymenoptera: Chalcididae) on Cricula trifenestrata (Helfer) from India. J Mun Ent Zool 7(1):222–225

    Google Scholar

  25. Tikader A, Vijayan K, Saratchandra B (2014) Cricula trifenestrata (Helfer)(Lepidoptera: Saturniidae)-A silk producing wild insect in India. Trop Lepidoptera Res 24:22–29

    Google Scholar

  26. UK C (2014) Cricula trifenestrata ((Helfer)), tea flush worm.[pest/pathogen]. Cricula trifenestrata ((Helfer)), tea flush worm.[pest/pathogen]., (AQB CPC record).

  27. Van Zwet AJ (1950) A practical method of cadavontrolling caterpillars in cinchona plantations. Bergcultures 19:331

    Google Scholar

  28. Yadav S, Kumar A (2004) New record of wild silk caterpillar, cricula trifenestrata helfer on large cardamom and notes on it's biology. In: Arvind K (ed) Advances in Life Sciences, 1st edn, Chapter 36. p 305

    Google Scholar

  29. Yamada H, Tsubouchi K (2001) Characterization of silk proteins in the cocoon fibers of Cricula trifenestrata. Int J Wild Silkmoth Silk (jpn) 6:47–51

    Google Scholar

  30. Yamada H, Kato Y, Tsubouchi K (2001) Yellow pigmentation of the fibroin core in the cocoon fibers of Cricula trifenestrata. Int J Wild Silkmoth Silk (jpn) 6:43–46

    Google Scholar

Download references

Acknowledgements

The authors wish to thank Central Silk Board, Bangalore, India for their constant support.

Funding

No funding received from any organisation.

Author information

Affiliations

Authors

Contributions

HH and BNS conceived and designed the experiments. HH, MM and SV performed the experiment and wrote the manuscript. PB and LG analyzed the data. LG and MM reviewed the manuscript. All authors have read and approved the manuscript.

Corresponding author

Correspondence to Hemachandran Hridya.

Ethics declarations

Ethics approval and consent to participate

Not applicable.

Consent for publication

The participants declare that the work has been consented for publication.

Competing interests

The authors declare that they have no competing interests.
