Usage of the cyto-genetics and cytology to identify the action mechanisms of two bio-fertilizers on Allium cepa meristematic cells
Bulletin of the National Research Centre volume 43, Article number: 138 (2019)
Bio-fertilizers as a safe alternative to the synthetic fertilizers come to the front in the agriculture requirements as they provide the planted crops with their nutrients to ensure high quality and productivity. Many of them must be screened and examined to configure their effect on the plants.
This study was designed to evaluate two promising bio-fertilizers: Moringa oleifera leaf extract (5.0, 10.0, 20.0%) and Sacharomyces cerevisiae aqueous extract (5.0, 10.0, 20.0%) for their safe usage on Allium cepa root meristems as a model system for monocots after 3.0 h of direct treatment. This evaluation focused on both cytogenetic and cytological levels. Cytogenetic studies screened the effect of each extract on the mitotic apparatus considering the mitotic index, mitotic phase index, percentage, and type of abnormalities. Cytological studies with transmission electronic microscope screen the effect of each extract on ultra-structural organelles (mitochondria, endoplasmic reticulum, peroxisomes, dictyosomes in addition to the vacuoles) in the cell cytoplasm. Obtained data revealed that the yeast extract shows a remarkable cytological effect on cytoplasmic organelles. By the same time, only the higher used concentration of Moringa extract shows higher chromotoxic effect on chromosomal DNA despite it shows high proliferation effect on the treated root tip cells.
Among the two tested bio-fertilizers, the Moringa extract in lower concentration is more preferable as it does not harm neither the cytoplasmic organelles nor the mitotic apparatus.
The increased awareness of the environmental problems associated with the farmers and plant breeder activities in agriculture to ensure his food requirements, such as depending on synthetic fertilizers and pesticides which were previously proved to pollute the soil and irrigation canals and reduce the crops’ quality and productivity, attempted researchers to reconsider the nature resources gifts as much safer alternatives over the currently used synthetic products. In this way, bio-organic fertilizers (as a source of input plant nutrients) may replace the synthetic ones. They can hopefully solve the dilemma of the obligatory needs for plant nutrient supplement without damaging the plant earth ecosystem or crops’ quality, due to their high productivity, high nutritive value, anti-oxidant effect, easy preparation, low cost, and environmentally safe (Phiri 2010).
Moringa oleifera is one of such promising alternatives being investigated to ascertain its effect on both growth and yield of crops and thus can be promoted among farmers as a possible supplement or substitute to inorganic fertilizers (Phiri 2010), e.g., Moringa leaf and twig extract increases the contents of growth-promoting hormones (auxins, gibberellins, and cytokinins) in Eruca vesicaria subsp. sativa (rocket or arugula) progressively above those of the corresponding controls in a dose-related manner (Abdalla 2013).
Moringa leaf extract was sprayed onto the leaves of onions, bell pepper, soya beans, sorghum, coffee, tea, chili, melon, and maize. It was shown to increase yields of these crops (Fuglie 2000). Moringa extract products can be employed either as root tips, soil drenches, or foliar sprays.
On the other hand, Sacharomyces cerevisiae (bread yeast) also is considered as a type of bio-fertilizer which is usually added to the soil or as foliar application on vegetable crops because of its nutrition properties as well as its substances like growth regulators such as gibberellins and auxins (Sarhan and Sharif 1988) and its ability to produce a group of essential enzymes (Dinkha and Elkhazraji, 1990).
Active dry yeast is considered as a bio-stimulant, natural source of cytokinins that stimulate cell division and enlargement as well as the synthesis of protein, nucleic acid, and chlorophyll formation (Wanas 2006). It may enhance water holding capacity, increase antioxidants, and enhance the metabolism (Abbas 2013).
The objective of the current study is to test the effect of Moringa leaf extract and bread yeast aqueous extract as two bio-fertilizers on the somatic cell division and on some cytoplasmic organelles such as the mitochondria of Allium cepa plant as a model system in order to configure its mode of action on monocot plants.
Materials and methods
The Allium cepa (2n = 16) onions (Var. red, Giza) were used for all the conducted experiments and were obtained from the Crop Research Institute, Agricultural Research Centre, Giza, Egypt.
Chemicals and experimental extracts
The chemicals for cytogenetic studies were prepared according to Sharma and Sharma (1980) with some modifications. The chemicals for cytological studies with transmission electronic microscope were prepared according to Reynold (1963) with some modifications. One hundred percent of Moringa plant extract was kindly prepared and obtained by The Plant Moringa Propagation Unit, National Research Center, Giza, Egypt.
One hundred percent of yeast extract is prepared in the cytology and cytogenetics lab, NRC, Egypt, after Hanafy et al.’s (2012) prescription as follows: various concentrations (5.0, 10.0, and 20.0 g) of yeast were weighed and put with 25.0 cm3 of water with a teaspoon full of sugar in glass beakers. The beakers of each concentration were kept in a dark warm place for 30 min, contents of the beakers were then filtered into a measuring flask, and water was added to 100.0 cm final volume for each one.
Treatment with the tested materials
The designed experiment was carried out on benchtop in cytology and cytogenetics lab, NRC, Egypt, as follows: about 2.0 cm length main roots of onion bulbs were treated for 3.0 h with the experimented materials for each concentration at room temperature and then divided into two groups for cytogenetic studies and cytological studies.
For cytogenetic studies
The roots were fixed with Carnoy’s fixative for 24 h and then preserved in 70.0% alcohol ready to be examined (Sharma and Sharma 1980). About 3000 of onion root tip meristem cells were scored and observed under an Olympus light microscope for each treatment. Mitotic index was computed by determining the mitotic cell frequency at the root tip cells as:
Cytological abnormalities at the appropriate mitotic stages were also observed and scored.
For cytological studies
This part of the study has been carried out in TEM lab CURP (Cairo University Research Park - Faculty of Agriculture). In summary, the roots were fixed in 5.0% gluteraldehyds in 0.1 M sodium cacodylate buffer, 7.3 pH; post-fixed in 1% osmium tetroxide in 0.1 ml sodium cacodylate buffer; immersed in a mixture of resin and propylene oxide; stained in toluidine blue for light microscope examination prior to final trimming; stained for ultra-thin sections: uranyl acetate 30 min followed by lead citrate for 15 min. The ultra-thin sections of tissue were stained with uranyl acetate and lead citrate and then examined by transmission electron microscope JEOL (JEM-1400 TEM) at the candidate magnification. Images were captured by CCD camera model AMT, optronics camera with 1632 × 1632 pixel formate as a side mount configuration. This camera uses a 1394 firewire board for acquisition.
Table 1 revealed an increase in the mitotic index values after treating the onion roots for 3 h with aqueous Moringa leaf extract in the two higher used concentrations; if compared with the control, the maximum mitotic index (11.63) was recorded after treatment with 10.0% Moringa extract followed by the mitotic index 9.28 recorded after 20.0% while treatment with 5.0% extract barely affect the mitotic index (8.03).
On the other hand, 3-h treatment with bread yeast extract shows a concentration-dependent reduction of mitotic index values (8.84, 7.94, and 6.26).
As illustrated in Table 1, although the treatment with 5.0% Moringa extract did not affect the mitotic index, it shows an increase in prophase frequency to reach 46.4% on the response of metaphase (8.02%) and ana-telophases (45.57%). This mode of action was reversed after the treatment with 20.0% Moringa extract, as there was a notable decrease in the prophase frequency on the response of metaphase frequency; the same was regarded after all treatment with the bread yeast extract concentrations on the mitotic phase duration.
Table 1 also reveals that all concentration treatments with each of the two examined materials increase the percentages of abnormal dividing cell of the onion root meristems. The 3-h treatment with Moringa extract was the most destructive, since it induced concentration-dependent increases in the percentages of abnormal mitoses reach 24.64% after treatment with 20.0% concentration, worth to mention that the concentration 20.0% of Moringa extract induces twice the percentage induced after the same used concentration of bread yeast extract.
Table 1 also illustrates that all concentration treatments with each of the two examined extracts exerted the highest percentage of abnormalities at the metaphase stage; these percentages declined at the ana-telophase stage except after treatment with 5.0% of bread yeast extract.
As illustrated in Fig. 1 the cytological investigations revealed that both tested materials induced a wide range of abnormalities distributed among the different mitotic stages (Table 2). These abnormalities can be classified into three groups arranged in the following general order of frequencies: chromatin material liquefaction abnormalities > chromosomes kinetic abnormalities > chromosomal structural aberrations, followed by less frequent dividing cells with micronuclei noticed only after treatment with 10.0% Moringa extract by the percentage of 0.6%.
Chromatin material liquefaction comprised of chromosome stickiness (Fig. 1) and sticky bridges. Generally, cells suffering stickiness of the chromosomes dominated. Stickiness was the most frequent abnormality observed after all concentrations of both tested materials, worth to mention that Moringa extract was the most destructive, since it induced the higher proceeding percentage (5.91, 6.37, and 23.23% ) of mitotic cells suffering stickiness of the chromosomes.
Chromosomes’ kinetic abnormalities comprised of cells with disturbed chromosomes (Fig. 1) and cells with lagging chromosomes (Fig. 1) in addition to clumped chromosomes at metaphases. As illustrated in Table 2, Moringa extract treatment in the three concentrations produces concentration-dependent lowered percentages of normal disturbance (Fig. 2) and clumped metaphases reach 1.13% after treatment with 20.0%, while the lagging chromosomes as a type of disturbance did not exist.
On the other side, the yeast extract produces considerable percentages of disturbance in its three forms compared with Moringa extracts and control; these percentages were not concentration dependent as it reaches 3.65.0% after treatment with 20.0% concentration which exceeds the percentage of disturbance induced by the same concentration of Moringa by nearly twice its value.
The obtained data revealed that the two tested materials were safe without mentioned clastogenic effect if compared with the control. A very ignorable percentage of micronucleus in mitosis was recorded only after treatment with 10.0% Moringa extract.
On the level of cytological investigations with transmission electronic microscope, Figs. 3 and 4 show that Moringa extract in its two lower concentrations found to be a much safer extract with non-mentioned stress on the ultrastructural organelles in the cell cytoplasm (clear cytoplasm, normal-sized nucleus, normal endoplasmic reticulum extended normally in the cytoplasm, mitochondria in healthy figure with no lysis or pores or degradation, normal dictyosomes, and small clear vacuoles) if compared with control (Fig. 2), only by the exception of the appearance of peroxisomes after treatment with 10.0% of Moringa extract. Raising the concentration of Moringa extract to 20.0% shows its effect on the clearance of the cytoplasm which became cloudy with hardly distinguishable organelles, many small vacuoles, peroxisomes, and other small organelles with crystal shiny core suspected to be electron-translucent bodies (Fig. 5).
On the other hand, treatment with bread yeast extract declares its effect on cytoplasmic organelles even after the lowest used concentration as it affected the cytoplasm to be much turbid and cloudy with a dilated endoplasmic reticulum weakly folded around the mitochondria and many small autophagic vacuoles with organelles engulfed in it, in addition to the presence of peroxisomes (Fig. 6). By exceeding the yeast extract concentrations to 10 and 20.0%, their effects on the cytoplasmic organelles became much fatal as it induces cytoplasm shrinkage away from cell wall, accumulated endoplasmic reticulum folded around partially degraded mitochondria, and huge autophagic vacuoles (Figs. 7 and 8).
The mitotic index variations as a parameter for cytotoxicity used as indicators of adequate cell proliferation (Gadano et al. 2002) and the types of chromosomal aberrations and their frequency used as a parameter for the genotoxic effects of the tested materials were analyzed and illustrated in Tables 1 and 2 and Fig. 1.
The increase in mitotic index values after the treatment of the onion roots for 3 h with Moringa leaf extract in the two higher concentrations compared with control may be due to the enrichment contents of growth-promoting hormones (auxins, gibberellins, and cytokinins) in Moringa extract (Abdalla 2013), and it may reflect the Moringa effect on DNA biosynthesis and the other substances required for cell division (El-Awadi 1996).
The yeast extract mito-depressive action may be due to a negative interference of this alcoholic extract with specific proteins and enzymes which mediate DNA polymerase (Hidalgo et al. 1989), DNA synthesis, blockage in the G2 phase of the cell cycle, inhibiting the cell to enter into divisional phases (0.4% v/v concentration of ethyl alcohol was proved earlier to delay the cell cycle for 13 h after given to the root tips of Allium cepa for 2 h, this delay cover the S and G phases (Arcara and Ronchi, 2014)), microtubule formation, impaired nucleoprotein synthesis, and reduced level of ATP to provide energy for spindle elongation, microtubule dynamics, and chromosomal movement (Majewska et al. 2003; Türkoğlu 2012; Gagliardi and Shain 2013).
There was a notable decrease in the prophase frequency on the response of metaphase frequency, after treatment with 20.0% Moringa extract and all treatment with the bread yeast extract concentrations on the mitotic phase duration. Similar effect on the phase frequency was observed previously by Ali (2009) after treatment of Vicia faba roots with the extract of “S. bicolor seedlings extract,” author attributed this effect to be due to the hinder of DNA synthesis rather than retardation of the spindle formation, where MI depression was not accompanied by lowering the metaphase and anaphase (same as yeast extract in all concentration).
The increase in metaphase and ana-telophase percentage could be the result from the lengthening of their duration that leads to their accumulation (Abdel-Salam et al., 1997).
Worth to mention that the alcohol produced by the yeast fermentation changes the PH of its extract; this PH acts as a controlling factor for microtubule disassembly/assembly probability ratios, as well as it controls its polymerization and depolymerization during metaphase chromosome orientation. This, in turn, controls the timing and dynamics of post-attachment mitotic chromosome motions through metaphase (Gagliardi and Shain 2013); this in turn affects the lengthening of metaphase and anaphase duration.
Considering the chromosomal aberrations as an indicator for the mutagenic effect of the tested materials on the following:
Chromosome DNA (chromotoxic effect) liquefaction abnormalities are interpreted to be the result of treatment which affect the depolymerization of DNA, partial dissolution of nucleoproteins or breakage and exchanges of the basic folded fiber unit of chromatids, and/or stripping of protein covering of DNA in chromosomes (Ignacimuthu and Saravana 1994; Asita and Mokhobo 2013). The presence of stickiness in the chromosomes reflected highly toxic effects, usually irreversible which might lead to cell death (Liu et al. 1995).
The chromosome kinetic abnormalities (turbogenic effect) are interpreted to be the result of treatment effect of the tested material on spindle mechanism disorder which controls chromosomes mobility and alignment in the cell cytoplasm. It comprised of cells with disturbed chromosomes and cells with lagging chromosomes in addition to clumped chromosomes at metaphases. As illustrated in Table 2, the lower turbogenic effect of Moringa extract may be explained by the severe chromotoxic effect of this extract, which induces increasing percentage of stickiness, and is much higher than its toxic effect on spindle fiber which affects the chromosome mobility in the cell cytoplasm.
Chromosome protein core (clastogenic effect) comprised of cells with breakage, fragments, and micro/macronucleus; in our evaluation, the obtained data revealed that the two tested materials were safe without mentioned clastogenic effect if compared with control as micronuclei noticed only after treatment with 10.0% Moringa extract by percentage 0.6%.
On the cytological level, the appearance of peroxisomes in the cell cytoplasm after treatment with 10.0% of Moringa extract may reflect the reaction of the cell defensive apparatus toward the treatment stress. Taking in mind that the meristemic cells under treatment with this 10.0% Moringa extract scored the highest mitotic index which itself is a cell stress but in a positive direction especially to the plant breeders.
It is well known that the mitochondria is a powerhouse of the cell as they convert the ADP into ATP through phosphorylation oxidation reaction to provide cell with energy to carry out its vital functions; it is also considered as a housekeeping organelles in the cytoplasm as it contains enzymes in its inner matrix; if leaks out through pores or ruptures in the outer mitochondria membrane would work on digesting the cell itself in a spontaneous suicide in a phenomenon known as apoptosis (Jones 2002). The presence of such defected mitochondria may give a convincing explanation for the effect of yeast extract on the cell proliferation as the reduction in the mitotic index may result from the reduced level of ATP mainly provided to the cell via mitochondria which extremely affected with yeast extract. Also, it is well known that the endoplasmic reticulum plays an essential role in spindle formation and transport chemically modified materials to different parts of the cell; if become dilated as a result of accumulation of the secreted incompetent materials within it or ruptured or even stressed would drive the cell to self-killing depending on the degree of damage. The presence of such defected endoplasmic reticulum after treatment with the yeast extract may give another explanation for the chromosomes kinetic abnormalities as a result of spindle disorder. Also, it is well known that the endoplasmic reticulum and mitochondria are organelles known as a device for protein synthesis which in turn reflects the activation of genes. The formation of dilated endoplasmic reticulum and the presence of numerous undifferentiated mitochondria may explain the gradual decrease in protein synthesis as the deleterious effect on them may block RNA synthesis or translation process as previously reported by Lord et al. (1991). On the other hand, the electron-translucent bodies are considered as a mechanism of recovery of damaged organelle because it reduces the transport of substances through the mitochondria pores (Selga et al. 2005).
The notable effect of the yeast extract on the cytoplasmic vital organelles may be attributed to its effect on the cell cytoplasm PH which is 7.4 in normal conditions where the cytoplasmic organelles can do their accurate function, as it is well known that yeast produces alcohol as a result of its anaerobic respiration which in turn changes the PH of the treated root tip cells. The alcohol-induced mitochondria and ER stress response fits this theory, because alcohol easily crosses the cellular membranes and affects all compartments inside the cell. Alcohol also impairs autophagy and triggers the lysosome and peroxisomes stress response to increase (Cheng 2015; Lugea et al. 2015).
After getting these two natural fertilizers investigated on both cytology and cytogenetic levels, the yeast extract shows to somewhat extent the more having remarkable cytological effect; their effect may be attributed to the mode of action of its extract on the PH of the cell cytoplasm of root tip meristems; by the same time, the higher used concentration of Moringa extract shows higher chromotoxic effect on chromosomal DNA despite it shows high proliferate effect on the treated root tip cells. To achieve the least mutagenic effect, lower concentrations might be used for the two bio-fertilizers under investigation.
