Trematode cercarial fauna obtained from the field-collected freshwater snails Lymnaea natalensis in Egypt
Bulletin of the National Research Centre volume 43, Article number: 86 (2019)
Lymnaea natalensis is the snail intermediate host for Fasciola spp. parasites. The purpose of the present investigation is to detect the different trematodes’ larval stages in this snail from three rural localities in Giza Governorate (ElZeidia, Oseem, and ElMansuria), Egypt as examples and detecting the percentage of infection with Fasciola spp. and other trematodes cercariae. The samples were collected and examined for parasitic cercariae infections by using cercarial emergence and crushing techniques.
From total examined snails, it was found that the infected snails included five types of the cercarial stages beside Fasciola cercariae and three types of metacercariae. These cercariae were xiphidio cercariae, gymnocephalus, echinostome cercariae, virgulate cercariae, Echinochasmus pelecani, and Palaeorchis cercariae. The infection rate in snails collected from ElZeidia was the higher infection rate (84%) than others from Oseem (76%) and ElMansuria (62%).
These findings confirmed that L. natalensis snails are not only a suitable intermediate host for Fasciola spp. but also for several parasites and play an important role in the transfer of different parasitic diseases to animals and humans.
Fasciolosis is one of the neglected tropical diseases (Beesley et al. 2017; WHO. World Health Organization 2017) and is caused by infection of trematodes belonging to the genus Fasciola spp. It is a serious infectious parasitic disease infecting humans and animals worldwide (Soliman 2008). Fasciola spp. causes disease of economic importance in sheep and cattle (Schweizer et al. 2005; Bennett and Pelaar 2005), with an estimated 250 million sheep and 350 million cattle at risk worldwide (Beesley et al. 2017; Hillyer and Apt 1997). Human fascioliasis is considered now as a zoonosis of major global and regional importance (Soliman 2008) as it is affecting nearly 50 million people worldwide (Rahman et al. 2017). Recently, the epidemiology of human fasciolosis had increased in the last two decades (Chaturvedi and Singh 2016). Individuals can also be infected by drinking water containing viable metacercariae (Sah et al. 2017), or by ingesting raw aquatic plants contaminated with the metacercariae (Lee et al. 2017). These liver flukes caused severe hepatic damage in the bile duct of the definitive hosts (Amer et al. 2016).
Freshwater snails served as intermediate hosts for a large number of trematode parasites in humans and animals (Lee et al. 2017; Chontananarth et al. 2017). Lymnaea snails are a group of freshwater snails distributed worldwide (Adediran and Uwalaka 2013) and Lymnaea natalensis snails were the main snail host for these liver flukes, Fasciola hepatica or gigantica, which were widely distributed in Africa (Moema et al. 2008). This infection had been recognized as a major constraint to animal farming, contributing to the impeded economic development in the developing countries (Amer et al. 2016).
In Egypt, liver flukes of Fasciola spp. negatively affected the farming industry and public health (Elshraway and Mahmoud 2017), and the liver fluke fragments were found in the Egyptian mummy (David 1997; Esteban et al. 2003). According to the Egyptian Academy of Scientific Research and Technology Report, losses in animal wealth due to fasciolosis in Egypt were estimated at 190 million annually. Also, human infection is a major public health problem in several areas of the world, including the Nile Delta in Egypt (Soliman 2008). Both acute and chronic fasciolosis have been found in almost all governorates and in the reclaimed desert land (Soliman 2008). Ashour et al. (2008) stated that it has a wide prevalence and distribution in the Egyptian Governorates, like Fayoum, Giza, Qaluobiya, Sharkiya, Dakahliya, Gharbiya, Kafr El-Sheikh, and Damiett Governorates and correlated the presence of these snails with the presence of the aquatic plants and the other snails. The infection rates of these snails were increased during summer months (Ahmed and Ramzy 1999; Hussein et al. 2005).
Lymnaea natalensis snails are involved in the life cycles of at least 71 trematode species belonging to 13 different families whose members use birds and both domestic and wild animals as definitive hosts (Brown 1978), and this without counting digeneans of lower vertebrates such as amphibians. These trematode species were varied according to the considered geographic region (Toledo et al. 1998) and local ecological characteristics (Esch and Fernandez n.d.). Lymnaeid species included different cercariae which were the larval form of different parasites. This field study was designed to gather information about different trematode cercariae present in L. natalensis snails beside Fasciola cercariae in three rural localities in Giza governorate, Egypt and so, can develop an initiative ways for their control.
Materials and methods
Collection of Lymnaea natalensis snails samples
The field groups included 3.130 L. natalensis snails collected during April 2016 to September 2017, from different irrigation canals belonging to three rural localities in Giza governorate namely Elmansuria, Elzeideia, and Oseem villages (Fig. 1). In each sampling site, the collection area covering 1 m2 through the agricultural canals. Snails found under water Lemna gibba leaves were collected manually by a sweeping net, where snails then loosen their hold on the plants and dropped to the bottom of the net (Fig. 2). Lymnaeid snails were found in areas where water was stagnant or presented only a slow current, usually in places where livestock was present.
Snails’ maintenance in lab conditions
Collected snails were transported by wet cotton to the lab at Theodor bilharz Research institute at the same day of collection. In Malacology laboratory, the snails were maintained in 60 × 30 × 30 cm plastic containers. Lymnaea snails were fed by lettuce 1–2 times per week and the water in the containers was changed once 24–48 h. Eggs were collected daily on transparent plastic sheets placed into the aquaria. These snails were identified morphologically as regards color, number of whorls, and diameter of the shell according to keys proposed by Ibrahim et al. (1999).
Collection and study of trematode larval stages
The collected snails were examined for larval trematodes infection by two methods that were carried out either by exposure of snails to artificial light for 1 h, at 25 °C, for cercarial shedding (Liang et al. 1987) or by crushing (Chu and Dawood 1970), where snails were crushed between two slides, and were carefully investigated under the dissection microscope. The collected cercariae were identified fresh or stained samples with iodine solution using light microscope. Non-shedding snails were kept in the laboratory and re-examined weekly to verify that cercariae were not shed by snails which could have been infected only shortly before being collected. When snails proved to be negative after several examinations by the shedding method, they were gently crushed in a Petri dish containing a small amount of dechlorinated water. The fleshy part of each snail was removed and was dissected under a microscope. The number of snails shedding cercariae and those presenting infection by intramolluscan larval stages were recorded. Cercarial types were classified according to Frandsen and Christensen (1984).
Raw data were analyzed statistically using SPSS software (IBM Software Company, USA). The percentage was calculated for all data as the number of infected individuals divided by number of individuals examined and multiplied by 100.
The external examination of the shell reveals that it is thin, fragile, with concavity on its side and a wide open funnel. Also, it is dextral, dark brown to black in color; the shell whorls were ranging from three to five in number and are spirally coiled (Fig. 3). As regards the size, it is about 12–16 mm (Table 1).
The present results show that the infection rate of snails infected with different trematode larvae that were collected from three rural localities in Giza governorate is higher in Elzeidia (84%) than others from Oseem (76%) and ElMansuria (62%) (Table 2).
During the present study, five species of cercariae, beside Fasciola cercariae, were found among the examined infected snails. The most abundant type was xiphidio cercaria, followed by gymnocephalus (faciolid) cercaria and echinostome cercariae (Fig. 4). These cercariae were divided into separate groups based on morphologically distinguishable differences in the shape and the length of the tail. All types of cercariae were single-tailed types and are classified as:
Xiphidio cercaria (Plagiorchidea):
The oral sucker has a stylet, and the ventral sucker located in the middle of the body with the same size of oral sucker; it develops in sporocysts (Plate 1, 1 and 2) and encystments in invertebrates, amphibians, and reptiles.
Gymnocephalus cercaria (Fasciolidae):
The length of its tail is almost as long as the body with dorso-ventral fin fold; the ventral sucker on mid-ventral surface of body and there is no stylet in the oral sucker. It develops in rediae and encysts on external substrates. It is produced by species of the family Fasciolidae (intestinal and liver parasites in herbivorous mammals). (Plate 1, 3 and 4).
Its tail is stout and as long as the whole body. The ventral sucker located on mid-ventral surface of body. It develops in rediae and encysts in invertebrates, fish, and amphibians. It is produced by species of the family Echinostomatidae (intestinal parasites of birds, reptiles and mammals) (Plate 2, 5).
It has a stout non forked tail; its length is shorter than its body and without finfolds. Ventral sucker is smaller than oral sucker, and a stylet located in the oral sucker (Plate 2, 6). It is produced by species of the family Lecithodendriidae (intestinal parasites of bats, birds, and amphibians) and by species of the genera Lymnaea and Melanoides.
Cercarial body is oval, white in color; tail is the same length as body, flexible, vacuole appearance along the tail. Cercariae were produced within rediae (Plate 2, 7). Esophagus was between pharynx and ventral sucker, ceca reaching to bladder, two main excretory tubes meet together before entering bladder. Genital primordia are two mass behind the ventral sucker.
Cercariaeum cercariae (Palaeorchis sp.):
Tail is absent, non-emerging cercariae, develop in rediae and encyst in snails. It is produced by species of the families Monorchiidae (intestinal parasites of fish) and Cyclocoelidae (parasites of the respiratory tract of birds) (Plate 2, 8). It is of no economic importance and is produced by species of the genera Biomphalaria, Gabbiella, and Lymnaea.
Types of metacercaria
Metacercariae had double thick cyst walls which were formed as a thin irregular wall secreted around the body of cercariae from its cystogenous glands and the tail then separated from the body (Plate 3). The present study reveals presence of:
Clonorchis sinensis metacercaria in mantle of L. natalensis snails. It is elliptical, has nearly equal sized two suckers and an excretory bladder found in posterior part of the body (Plate 3, 9). It also encysted in the flesh of freshwater fish.
Plagiorchis elegans metacercaria in the mantle of the snails (Plate 3, 10). Encysted inside the shell of L. natalensis.
Fasciola metacercaria (recently formed) shortly after emerged from snail or after crushing snails formed on slides (Plate 3, 11).
Freshwater snails play an important role in the veterinary field and also affecting the health of the public (Chontananarth et al. 2017). Fasciolosis is a major public health problem in several areas of the world, including the Nile Delta in Egypt (Soliman 2008). L. natalensis is the most common species prevalent in Egypt compared to other species such as L. columella, L. truncatula, and L. stagnalis (Ashour et al. 2008).
The external examination of the shell of L. natalensis snails revealed that they were thin, fragile, dextral, dark brown to black in color; the shell whorls were ranging from three to five in number and are spirally coiled. These results are in accordance with (El-Dafrawy and Taha 2007), who stated that the shell height ranging between 10 and 20 mm and the shell whorls were always ranging from 3 to 5 in number in L. natalensis snails collected from Giza governorate.
The present study showed that the infected snails include six types of cercariae and three types of metacercariae. These cercariae included xiphidio, gymnocephalus (fasciolid), echinostome, virgulate, echinochasmus pelecani, and Palaeorchis cercariae. The highest percentage of cercariae in all snails was xiphidio cercaria followed by echinostome and gymnocephalus. This agrees with the findings of Hussein et al. (2005) and Hussein and Khalifa (2010) who stated that the infection with xiphidio cercariae was the most prevalent in Qena Governorate, Upper Egypt, followed by echinostome cercaria. A xiphidio cercaria and an echinostome were described in Alexandria (Allam 1992). Also, the xiphidio cercaria was found to be the most abundant single-tailed cercariae in the habitats examined in the proximity of Pretoria (Moema et al. 2008). These cercariae encyst in invertebrates, amphibians, and reptiles (Frandsen and Christensen 1984). In previous studies, it has been shown that xiphidio cercaria larvae belong to Plagiorchidae trematodes (Yaraghi et al. 2011). Sharif et al. (2010) stated that Lymnaea gedrosiana from the Mazandaran Province were found to be infected with the Plagiorchidae, Clinostomidae, and Echinostomatidae and stated that xiphidio metacercariae were found encysted in various second intermediate hosts, i.e., in the gill chambers of freshwater shrimps and in the mantle of L. natalensis. Also, Faltýnková et al. (2007) stated that L. stagnalis, the great pond snail in Central Europe, were infected with 24 trematode species comprising 19 species of cercariae and 11 species of metacercariae (six species occurred both as cercariae and metacercariae) of eight families. The dominant cercariae were those of Opisthioglypheranae, Plagiorchis elegans, and Echinostomatidae, and 14 double infections were found.
The echinostomatid cercariae were known as avian parasites and xiphidio cercariae were parasitized avian and amphibians (Moema et al. 2008). The primary intermediate host of Plagiorchis is freshwater snail and the secondary intermediate hosts are fishes, snails, and arthropods (Rivaz et al. 2014). Palaeorchis sp. (family Monorchidae) is widely distributed fish parasites, whose larvae can use several snail species as their first intermediate host (Mastitsky 2007; Zdun 1961). The cercaria, according to the main features of morphology, was identified as echinochasmid and attributed to the genus Echinochasmus. The intermediate hosts of Echinochasmus cercariae are mainly freshwater prosobranch gastropods (Stanevičiūtė et al. 2008). The life cycles of less than half from approximately 50 known species of the genus Echinochasmus have been studied (Fried 2001). A wide range of fish-eating birds and mammals are known as final hosts of Echinochasmus spp. (Kostadinova and Gibson 2000). The fact that echinochasmid trematodes can infect man orally via the cercarial stage in contaminated water is of considerable interest to the medical community (Taylor et al. 2001). The present results showed the presence of three types of metacercariae which encysted in various second intermediate hosts, i.e., in the gill chambers of freshwater shrimps and in the mantle of L. natalensis. These results are in accordance with Faltýnková et al. (2007) who reported 11 species of metacercariae (six species occurred both as cercariae and metacercariae) of eight families in L. stagnalis, the great pond snail in Central Europe.
The present results showed that the infection rate in Elzeidia was higher than that in Oseem and ElMansuria being 84%, 76%, and 62%, respectively. This agreed with Ashour et al. (2008) who stated that the infection was present in Fayoum, Damietta, Qaluobiya, and Kafr El-Sheikh; Gharbiya, Dakahliya, Sharkiya, and Giza Governorates, which may be attributed to the presence of the aquatic plants Lemna gibba and Jussiaea repens. Also, Nagaty et al. (1959) stated that the possibility of infection of Lymnaea sp. with Fasciola gigantica is higher in snails with large size.
The present study investigated the trematode fauna that were present in L. natalensis snails beside fasciolid cercariae and confirmed the presence of other cercarial species in three rural areas in Giza governorate, Egypt. These findings had served as an initial step for understanding the epidemiological situation and establishment of control programs of trematode infections in humans and animals. Thus, the complimentary studies seem necessary for survey of prevalence of trematodes in this snail all over the governorate.
Adediran OA, Uwalaka EC (2013) Laboratory breeding of Lymnaea natalensis (Krauss, 1848), intermediate host of Fasciola gigantica (Cobbold, 1856). New York Sci J 6(8):55–57
Ahmed AH, Ramzy RMR (1999) Infection of two lymnaeid snails with Fasciola gigantica in Giza, a field study. J Egypt Soc Parasitol 29:687–696
Allam A (1992) Studies on the Lymnaea-Fasciola (Host--parasite) relationships in Abis area. In: Ph. D. Thesis, High Institute of Public Health, Alexandria University, Egypt
Amer S, ElKhatam A, Zidan S, Feng Y, Xiao L (2016) Identity of Fasciola spp. in sheep in Egypt. Parasit Vectors 9(1):623
Ashour AA, Mostafa BB, Taha HA, Azzam AMA (2008) Distribution of natural populations of Lymnaea snails in some Egyptian governorates and their natural infection with Fasciola. J Environ Sci 16(1):19–31
Beesley NJ, Williams DJL, Paterson S, Hodgkinson J (2017) Fasciola hepatica demonstrates high levels of genetic diversity, a lack of population structure and high gene flow: possible implications for drug resistance. Int J Parasitol 47(1):11–20 Available from: http://linkinghub.elsevier.com/retrieve/pii/S0020751916302569
Bennett R, Pelaar J (2005) Updated estimates of the costs associated with thirty four endemic livestock diseases in Great Britain: a note. J Agric Econ 56(1):135–144 Available from: http://doi.wiley.com/10.1111/j.1477-9552.2005.tb00126.x
Brown DS (1978) Pulmonate molluscs as intermediate hosts for digenetic trematodes. Pulmonates 2:287–333 Academic Press London
Chaturvedi D, Singh VK (2016) Toxicity of Chlorophyllin against Lymnaea acuminata at different wavelengths of visible light. Trop Life Sci Res 27(2):25–36 Available from: http://www.tlsr.usm.my/tlsr27022016/27022016_03.pdf
Chontananarth T, Tejangkura T, Wetchasart N, Chimburut C. Morphological characteristics and phylogenetic trends of trematode Cercariae in freshwater snails from Nakhon Nayok Province, Thailand. Korean J Parasitol 2017;55(1):47–54. Available from: http://parasitol.kr/journal/view.php?doi=10.3347/kjp.2017.55.1.47
Chu KY, Dawood IK (1970) Cercarial production from Biomphalaria alexandrina infected with Schistosoma mansoni. Bull World Health Organ 42(4):569
David AR (1997) Disease in Egyptian mummies: the contribution of new technologies. Lancet 349(9067):1760–1763 Elsevier
El-Dafrawy SM, Taha HA (2007). Morphological and molecular characterization of Lymnaea natalensis, the snail vector of Fasciola gigantica, in some Egyptian governorates. Egypt J Zool (48):347–69.
Elshraway NT, Mahmoud WG (2017) Prevalence of fascioliasis (liver flukes) infection in cattle and buffaloes slaughtered at the municipal abattoir of El-Kharga, Egypt. Vet world 10(8):914
Esch GW, Fernandez JC (1994) Snail-trematode interactions and parasite community dynamics in aquatic systems: A review. Am Midl Nat 209-237.
Esteban J, Gonzalez C, Curtale F, Muñoz-Antoli C, Valero MA, Bargues MD, El-Sayed M, El-Wakeel AA, Abdel-Wahab Y, Montresor A, Engels D, Savioli L, Mas-Coma S (2003) Hyperendemic fascioliasis associated with schistosomiasis in villages in the Nile Delta of Egypt. Am J Trop Med Hyg 69(4):429–437
Faltýnková A, Našincová V, Kablásková L (2007) Larval trematodes (Digenea) of the great pond snail, Lymnaea stagnalis (L.), (Gastropoda, Pulmonata) in Central Europe: a survey of species and key to their identification. Parasite. EDP Sci 14(1):39–51 Available from: http://www.parasite-journal.org/10.1051/parasite/2007141039
Frandsen F, Christensen N (1984) An introductory guide to the identification of cercariae from African freshwater snails with special reference to cercariae of trematode species of medical and veterinary importance. Acta Trop 41:181–202
Fried B (2001) Biology of echinostomes except Echinostoma. Adv Parasitol 49:163–210 Available from: http://linkinghub.elsevier.com/retrieve/pii/S0065308X01490403
Hillyer GV, Apt W (1997) Food-borne trematode infections in the Americas. Parasitol Today 13(3):87–88 Available from: http://linkinghub.elsevier.com/retrieve/pii/S0169475897010004
Hussein AA, Califa RMA, MasComa S (2005) Trematode larval stages infecting Radix natalensis (Gastropoda: Lymnaeidae) in Qena governorate, Egypt, with special reference to fasciolid cercariae. Res Rev Parasitol 66(1–4):69–74
Hussein ANA, Khalifa RMA (2010) Fascioliasis prevalences among animals and human in upper Egypt. J King Saud Univ – Sci 22(1):15–19 Available from: http://linkinghub.elsevier.com/retrieve/pii/S1018364709000469
Ibrahim AM, Bishai HM, Khalil MT (1999) Freshwater molluscs of Egypt. National Biodiversity Unit, Egyptian Environmental Affairs Agency, EEAA
Kostadinova A, Gibson D (2000) The systematics of the Echinostomes. In: Fried B, Graczyk TK (eds) Echinostomes as experimental models of the biological research. Kluwer Acad Publ, Dordrecht, pp 31–57
Lee JH, Quan JH, Choi IW, Park GM, Cha GH, Kim HJ, Yuk JM, Lee YH (2017) Fasciola hepatica: infection status of freshwater snails collected from Gangwon-do (province), Korea. Korean J Parasitol 55(1):95
Liang YS, Bruce JI, Boyd DA (1987) Laboratory cultivation of schistosome vector snails and maintenance of schistosome life cycles. In: Proc first Sino-am Symp, pp 34–48
Mastitsky SE (2007) First report of parasites in Lithoglyphus naticoides (Gastropoda: Hydrobiidae) from Lake Lukomskoe (Belarus). Aquat Invasions 2(2):149–151
Moema EBE, King PH, Baker C (2008) Cercariae developing in Lymnaea natalensis (Krauss, 1848) collected in the vicinity of Pretoria, Gauteng Province, South Africa. J Vet Res 75(3):215–223
Nagaty HF, EL-GINDY HS, ABDEL M (1959) On the morphology, anatomy and trematode infection of some lymnaeid snails from Egypt with special reference to fascioliasis. J Egypt Vet Med Assoc 19(1/2):51–77
Rahman AKMA, Islam SKS, Talukder MH, Hassan MK, Dhand NK, Ward MP (2017) Fascioliasis risk factors and space-time clusters in domestic ruminants in Bangladesh. Parasit Vectors 10(1):228
Rivaz S, Nasiri V, Karimi G, Abdigoudarzi M, Paykari H, Motamedi G et al (2014) Lymnaea stagnalis (Linnaeus, 1758) snails’ infection to trematoda larval stages in Shahrekord city’s springs. Asian Pacific J Trop Dis 4:S246–S249 Available from: http://linkinghub.elsevier.com/retrieve/pii/S2222180814604485
Sah R, Khadka S, Khadka M, Gurubacharya D, Sherchand JB, Parajuli K, Shah NP, Kattel HP, Pokharel BM, Rijal B (2017) Human fascioliasis by Fasciola hepatica: the first case report in Nepal. BMC Res Notes 10(1):439
Schweizer G, Braun U, Deplazes P, Torgerson PR (2005) Estimating the financial losses due to bovine fasciolosis in Switzerland. Vet Rec 157(7):188–193
Sharif M, Daryani A, Karimi SA (2010) A Faunistic survey of Cercariae isolated from Lymnaeid snails in central areas of Mazandaran, Iran Pakistan. J Biol Sci 13(4):158–163 Available from: http://www.scialert.net/abstract/?doi=pjbs.2010.158.163
Soliman MFM (2008) Epidemiological review of human and animal fascioliasis in Egypt. J Infect Dev Ctries 2(03):182–189 Available from: http://www.jidc.org/index.php/journal/article/view/260
Stanevičiūtė G, Petkevičiūtė R, Kiselienė V (2008) Digenean parasites in prosobranch snail Lithoglyphus naticoides population with the morphological description of Echinochasmus sp. cercaria. Ekologija 54(4):251–255 Available from: http://versita.metapress.com/openurl.asp?genre=article&id=doi:10.2478/v10055-008-0037-6
Taylor LH, Latham SM, Woolhouse MEJ (2001) Risk factors for human disease emergence. Philos Trans R Soc B Biol Sci 356(1411):983–989 Available from: http://rstb.royalsocietypublishing.org/cgi/doi/10.1098/rstb.2001.0888
Toledo R, Muñoz-Antolí C, Pérez M, Esteban JG (1998) Larval trematode infections in freshwater gastropods from the Albufera Natural Park in Spain. J Helminthol 72(01):79. Available from: http://www.journals.cambridge.org/abstract_S0022149X00001024
WHO. World Health Organization. Neglected Tropical Diseases Program 2017
Yaraghi AAS, Farahnak A, Eshraghian MR (2011) Haemolymph components of infected & none infected Lymnaea snails with Xiphidiocercariae. Iran J Parasitol 6(1):86 Tehran University of Medical Sciences
Zdun VI (1961) Larvae of trematodes in freshwater molluscs of Ukraine. Ukr Acad Sci Press, Kiev, p 141
Availability of data and materials
All the data obtained during the study are presented in this manuscript. Any further enquiries for additional information are available upon request from the corresponding author.
Ethics approval and consent to participate
Ethical approval had been granted approval by the Ethics Committee of Theodor Bilharz Research Institute (TBRI).
Consent for publication
The authors declare that they have no competing interests.
